Denon AVR-X3500H Service Manual

EXPLODED VIEW
Parts List :
http://dmedia.dmglobal.com/Document/DocumentDetails/24548
C X2
(SOCKET, POWER AC)
L X14
K X30
1
2
4
6
7
8
9
5
P4
P5
11
12
15 X4
16 X4
14X2
17
20
21 X5
B x4
A x6
A X2
A x2
H X21
A X5
D x7
M X2
A
P X2
A
P17
26
27 X2
27 X1
HDMI JACK/TUNER PACK/M3 BRACKET
30
(FRONT PCB&FUNCTION PCB
H/P PCB&USB PCB&FRONT HDMI PCB)
34
3
AVR-X3500BKE3
6
24
32
34
37
F
42
P3
P1
P7
A X5
P11
P20
P15
P10
P14
A X6
A X2
P9
P13
P12
A
P9-1 X2
P9-3
P9-8 X7
P13-1
P1-1
P3-1
23
J X3
K X3
J X3
29 X2
25X2
F
P12-1
P12-1
P12-2
P12-3
P19-2
P19-3
P19-1
P19
22
A
P8
P8-1
P8-2
P8-3
P8-4
D
35
P18
13
G x4
N x5
36
A
P7-2
P7-1
P7-3
P7-4
P13-2
P13-4
P13-3
A X1
44
T1
T3
T2
T1
T3
T2
T1
T3
T2
T1
T3
T2
T1
T3
T2
T1
T3
T2
T1
T3
T2
P9-2
E X2
33
45
O
A
A X18
46
47
46
P1-3
P1-2
P2
A X2
P12-4
39
K
10
43
41
31
28
28
P7-5
z
z
A-1
A-2
A-3
A-4
A-1
A-2
A-3
A-4
WARNING:
Parts marked with this symbol
z
have critical characteristics.
Use ONLY replacement parts recommended by the manufacturer.
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
76

Denon AVR-X3500H Specifications

General

Receiver type	Surround
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	215 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, Spotify, Tidal, TuneIn, iHeartRadio
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP
HDMI in	8
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Speakers connectivity type	Binding post
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	390 mm
Width	434 mm
Height	167 mm
Weight	10800 g
