Denon AVR-X3500H Service Manual

4. AUDIO
4.1. AUDIO CHECK
No audio output
Check the ANALOG AUDIO BLOCK
Check the DIGITAL AUDIO BLOCK
Check the ADC BLOCK
Check the HDMI BLOCK
Check for other causes
Check the HDMI BLOCK
See "Service Path Check Mode"
Check the DIGITAL AUDIO BLOCK
CHECK 1 INPUT SURROUND MODE SOURCE
Audio output OK? ANALOG 2CH DIRECT ANALOG
CHECK 2 INPUT SURROUND MODE SOURCE
Audio output OK? COAX or OPT -
Legacy
(PCM or DolbyDigital or dts…)
CHECK 4 INPUT SURROUND MODE SOURCE
Audio output OK? HDMI -
Legacy
(PCM2ch or DolbyDigital or dts…)
CHECK 6 INPUT Connect
AVR's (connected in HDMI) audio out-
put OK?
HDMI This unit's HDMI OUT → Other AVR's HDMI IN
Setting SURROUND MODE SOURCE
CEC STANDBY - HBR audio(DolbyTrueHD or dtsHD MA)
CHECK 5 INPUT SURROUND MODE SOURCE
Audio output OK? HDMI -
HBR audio
(DolbyTrueHD or dtsHD MA)
CHECK 3 INPUT SURROUND MODE SOURCE
Audio output OK? ANALOG 2CH MULTICH STEREO ANALOG
NO
NO
NO
NO
YES
YES
YES
YES
YES
NOYES
NOYES (DIGITAL AUDIO BLOCK is OK)
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
84

Denon AVR-X3500H Specifications

General

Receiver type	Surround
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	215 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, Spotify, Tidal, TuneIn, iHeartRadio
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP
HDMI in	8
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Speakers connectivity type	Binding post
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	390 mm
Width	434 mm
Height	167 mm
Weight	10800 g
