Denon AVR-X3500H Service Manual

DIAGNOSTIC MODE
Service Path Check Mode
1.1. Actions
This function is convenient for conrming problem paths in the product and checking the paths after repairing.
The video system and audio system operation paths can be checked.
The backup data is not rewritten.
1.2. Starting up
While holding down buttons "
ZONE2 SOURCE
", "
DIMMER
" and "
STATUS
" simultaneously, press the power button to turn on the power.
Select the "
1. SERVICE CHECK
" using the "
TUNER PRESET CH +
" button, then press the "
STATUS
" button then to conrm.
The "
TUNED
", "
STEREO
" and "
RDS
" segments are lit in this mode.
1.3. Canceling diagnostic mode
Press the power button to turn off the power.
1.4. Selecting items to check
Press the
q
button to switch between video items and audio items.
Press the
w
or
e
button to select the previous or next item.
The unit Remote control unit
Actions
q w e q w e
Audio ⇔ Video PREVIOUS NEXT Audio ⇔ Video PREVIOUS NEXT
Button DIMMER QUICK SELECT 1 QUICK SELECT 2 SLEEP CURSOR
0
CURSOR
1
1.5. Audio system conrmation items
See the block diagram g.AXXth.
Paths to be conrmed Display Settings What to conrm
1 Analog g.A01
A01:ANALOG PASS
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : DIRECT
Amp assign : Surround Back
MAIN ZONE : On
ZONE2 : Off
・ Analog input ⇒ Speaker output (Front L/R)
・ Analog input ⇒ Pre OUT output (Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
2
DIGITAL
(MAIN)
g.A02a
g.A02b
A02:DIGITAL
Input Source : CBL/SAT
Input Mode : DIGITAL (xed)
Sound mode : MULTI CH STEREO
Amp assign : Surround Back
Speaker Cong ALL Speaker = Small / SW = Yes(2ch)
MAIN ZONE : On
ZONE2 : Off
・ Digital input ⇒ Pre output (Front L/R, Center, Surround L/R, Surround Back L/R)
・ Digital input ⇒ Pre output (Front L/R, Center, Surround L/R, Surround Back L/R, Subwoofer1/2)
(
b
The input source can be switched to any source except CBL/SAT.)
3
DIGITAL
(ZONE2)
g.A03a
g.A03b
A03:DIGITAL-Z2
Input Source : HEOS Music
Input Mode : Auto
Sound mode : STEREO
Amp assign : ZONE2
MAIN ZONE : On
ZONE2 : On
・ Digital(PCM) input ⇒ Speaker output (Surround Back (ZONE2) L/R)
・ Digital(PCM) input ⇒ Pre OUT output (ZONE2 L/R)
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
150

Denon AVR-X3500H Specifications

General

Receiver type	Surround
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	215 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, Spotify, Tidal, TuneIn, iHeartRadio
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP
HDMI in	8
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Speakers connectivity type	Binding post
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	390 mm
Width	434 mm
Height	167 mm
Weight	10800 g
