Denon AVR-X3500H Service Manual

See the table below for details on error codes and solutions when updating the rmware.
Error codes are displayed in 4 digits,
YYXX
(
YY
: DeviceID,
XX
: ErrorCode).
Update–––**% **m
↓
Update ErrorYYXX
Update ErrorYYXX (YY : DeviceID, XX : ErrorCode)
↓↑ The display is alternately displayed.
Please check you
Content of the display is scrolled.
Remedies
Error Code
(
YYXX
)
(DeviceID/ErrorCode)
Remedies
000A
"Connection failed. Please check your network, then try again."
0009
"Update failed. Please check your network, then try again."
0009
"Upgrade failed. Please check your network, then try again."
YY00 YY01
YY02 YY03
YY04 YY07
"Please check your network, unplug and reconnect the power cord, and try again."
YY00 YY01
YY02 YY03
YY04 YY07
"Please unplug and reconnect the power cord, and try again."
0005
"Incompatible update le found on the USB device. Please check the le."
0006
"Update le is corrupted. Please check the le."
000B
"Please contact customer service in your area."
b
Check the power supply and communication lines of each device.
Device ID table
Device ID (
YY
) Device Name
00
General
01
Main CPU
0B
Main FBL (No used)
11
DSP1 or DSP
12
DSP2
b
Except : AVR-S640H/S740H/S940H/X1500H/X2500H/X3500H
13
DSP3
b
Except : AVR-S640H/S740H/S940H/X1500H/X2500H/X3500H
19
DSP4
b
Except : AVR-S640H/S740H/S940H/X1500H/X2500H/X3500H
15
Audio PLD
22
Video PLD
b
Except : AVR-S640H/S740H/S940H/X1500H/X2500H
2A
GUI
2B
PIMG
b
ONLY : S640H/S740H/S940H/X1500H/X2500H
33
LEGO
Error Code table
Type code (
XX
) Description
00
Logical error
01
Error during erasing
02
Error during writing
03
Error during verifying
04
No access for the component
05
Package mismatched.
Product ID, package version un-matched of the package manifest
06
Unpack dis-available of component package le
07
Time out
08
Latest rmware has already installed.
09
Error during download
0A
Error connection
0B
Hardware Error
---Checking the Firmware Version After the Update---
After updating the rmware, check the version.
See "1. Version Display Mode"
7. About the error codes
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
187

Denon AVR-X3500H Specifications

General

Receiver type	Surround
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	215 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, Spotify, Tidal, TuneIn, iHeartRadio
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP
HDMI in	8
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Speakers connectivity type	Binding post
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	390 mm
Width	434 mm
Height	167 mm
Weight	10800 g
