Denon AVR-X3500H Service Manual

CENTER, SURROUND, SURR.BCK ch
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
0dBFS = +/-2.8Vpp=1.98Vrms
AVR-X3500H
LEVEL DIAGRAM
CENTER ch
SURROUND ch
SURR.BCK ch
-2
.0
-
0.
5
=-2
.
5d
B
+30dB
SP OUT
4.23Vrms/8Ω
+
2
9dB
-
2.0
-
0.5+
3
.0=+
0
.5dB
MAX
SI
GNA
L
LE
V
EL
D
O
L
B
Y
LIM
IT
LE
V
E
L
(
AL
Lc
h-
3dB
F
S)
0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
AK4458
-0.4dB
Differential Out
NJU72343 MAX. OUTPUT 4.2Vrms
＋
＋
SPEAKER
OUT
D
SP
GAIN
ADJ.
AK4458VN
D/A
－
－
＋
P
LD
NJU72343
PREOUT
DD INPUT:-20dBFS 1kHz
DSP OUTPUT:-20dBFS
ANALOG INPUT:200mVrms L+R 1kHz
(MODE:MULTI CH STEREO)
DSP OUTPUT:-23.0dBFS
PREOUT
159mVrms
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
45

Denon AVR-X3500H Specifications

General

Receiver type	Surround
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	215 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, Spotify, Tidal, TuneIn, iHeartRadio
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP
HDMI in	8
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Speakers connectivity type	Binding post
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	390 mm
Width	434 mm
Height	167 mm
Weight	10800 g
