Denon AVR-X3500H Service Manual

ZONE2 ch
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
LINE IN
AVR-X3500H
LEVEL DIAGRAM
ZONE2
-2
.
5dB
200mV
+30dB
SP OUT
4.23Vrms/8Ω
+
29
d
B
MAX
S
IGN
A
L
L
E
V
EL
NJU72343 MAX. OUTPUT 4.2Vrms
LINE IN
＋
SPEAKER
NJU72750
GAIN
ZONE2
NJU72343
NJU72343
NJU72750
PCM5100
D/A
GAIN
M
ON
O
M
ONO
MO
N
O
NJW1194
T
O
N
E
from
DA SB-ch
0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
PCM5100
0dBFS = 2.0Vrms
To MAIN
ZONE
PREOUT
150mVrms
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
47

Denon AVR-X3500H Specifications

General

Receiver type	Surround
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	215 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, Spotify, Tidal, TuneIn, iHeartRadio
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP
HDMI in	8
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Speakers connectivity type	Binding post
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	390 mm
Width	434 mm
Height	167 mm
Weight	10800 g
