Denon AVR-X3500H Service Manual

DIGITAL AUDIO DIAGRAM
MUX
DA-C
IN_0
IN_1
IN_3
Z2DIRBCK
Z2DIRDATA
Z2DIRPERR
PLDADCBCK PLDADCLRCK
Z2_DAC_FS
DA-FR
DA-C
DAC_FS
DA-SR
DA-SL
DACDATAS
DA-SBL
DA-SBR
ADINZ2L
ADINZ2R
ADINL
ADINR
ZONE2_D/A_R
ZONE2_D/A_L
LEGO_D/A_R
LEGO_D/A_L
DA_SW1 DA_SW2
DA-FL
DA-SL
DA-SBR
Z2_DAC_256FS LEGO_DAC_64FS LEGO_DAC_DATA
SUBWOOFER_DAC_64FS SUBWOOFER_DAC_DATA
OPTICAL 2
OPTICAL 1
COAXIAL1
DIGITAL IN
RX+/-
IN_0
IN_1
IN_3
27MHz
TMDS
LEGO SPDIF
OUT_1
TMDS
OUT_0
TMDS
IN_0
IN_3
LEGO_SPDIF
Z2HDMISPDIF
O2
C2
C1
MUX
TMDS
24.576MHz
ADC
DOUT
DIRADATAI
DIRABCKI
DIRDATA
64FSDIR1
SBCK
TXBCK
RXSPDIF
RXI2S
RXBCK
RXLRCK
TMDS
TMDS
TMDS
DATASW2
DATAS
DATAF
DSP1INSB/SR
DSP1INCSW/C
DSP1IN_/FR
DSP1INF/FL
DSP1IN64FS
HDMI OUT2
COAXIAL2
FRONT USB
6
5
4 23 1
GND
DATA-
VBUS
DATA+
ANT1
ANT2
HDMI IN
USB_Tx_Rx
TX+/-
IN_2
LEGO I2S
Z2DIRMCK Z2DIRPCM
Z2DIRLRCK
IN_1
IN_2
HDMISPDIF
O1
27MHz
TMDS
DIR
PCM9211
DIR+A/D
DIRLRCK
DIRALRCKI
DIRAMCKI
256FSDIR1
DIRXMCK
SLRCK
PLDADCMCK PLDADCDATA
TXLRCK
TXI2S
RXINT0
RXMCK
DA-FL
27MHz
DAC_256FS
DACDATAF
DAC_64FS
DACDATAC
DACDATASB
ARC
DATACSW1
DATASB
DSP1INS/SL
DSP1IN_/SW
DSP1INFS
24.576MHz
Oscillation
Amplifier
MAIN
OUT
PORT
SCK
LRCK
BCK
DA-FR
DA-SR
DA-SBL
Z2_DAC_64FS Z2_DAC_DATA LEGO_DAC_256FS LEGO_DAC_FS
SUBWOOFER_FS SUBWOOFER_DAC_256FS
HDMI OUT1
SERIAL
FLASH
HDMI7
HDMI4
HDMI3
HDMI1
SN74AHCU04PWR
Z2DIRSPDIF
OUT_1
MPIO_A
SELECTOR
DSP1OUT64FS
OUT_0
TMDS
RJ-45
HDMI6
HDMI5
HDMI2
FRONT
HDMI
iPod Auth.
MFI337S3959
AD8195
BUFFER
OUT_0
ADC
AK5358BET
MPIO_C
SELECTOR
PCM5100
ZONE2 DAC
PCM5100
LEGO DAC
AK4458VN
MAIN DAC
DSP1OUTFS
DSP1INMCK
TMDS
OUT_1
TMDS
64Mbit
SDRAM
LEGO MODULE
( AIOS4.0V )
MN864788
HDMI2.0
Matrix SW
(2.2 4 INPUTS)
PCM5100
SUBWOOFER
DAC
TO ANALOG AUDIO BLOCK
LC89091
ZONE2 DIR
USB_VBUS_ON/OFF
Wi-Fi BT ANT
HDMI ZONE2
CS49844A
Quad Core
DIGITAL AUDIO
DECODER
MN864788
HDMI2.0
Matrix SW
(2.2 4 INPUTS)
MN864787
HDMI (TX / RX / OSD / Scaler )
(1080p -> 4K/60 )
AVR_X3500 DIGITAL AUDIO DIAGRAM
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
50

Denon AVR-X3500H Specifications

General

Receiver type	Surround
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	215 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, Spotify, Tidal, TuneIn, iHeartRadio
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP
HDMI in	8
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Speakers connectivity type	Binding post
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	390 mm
Width	434 mm
Height	167 mm
Weight	10800 g
