DISASSEMBLY
Flowchart
• Remove each part following the ow below.
• Reassemble the removed parts in the reverse order.
• Read "SAFETY PRECAUTIONS" before reassembling the removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the work. Failure to shape the wires correctly may cause problems such as noise.
• See "EXPLODED VIEW"
FRONT PANEL ASSY
DISASSEMBLY
1. FRONT PANEL ASSY
and "EXPLODED VIEW"
FRONT HDMI PCB
Ref. No. of EXPLODED VIEW : P 1
USB PCB
Ref. No. of EXPLODED VIEW : P 2
FRONT PCB
Ref. No. of EXPLODED VIEW : P 3
FUNCTION PCB
Ref. No. of EXPLODED VIEW : P 4
CNT PCB
Ref. No. of EXPLODED VIEW : P 5
TOP_GUIDE PCB
Ref. No. of EXPLODED VIEW : P 18
TOP COVER
TRANS
DISASSEMBLY
8. TRANS
and "EXPLODED VIEW"
POWER TRANS
Ref. No. of EXPLODED VIEW : 13
RADIATOR ASSY
DISASSEMBLY
2. RADIATOR ASSY
and "EXPLODED VIEW"
AMP PCB
Ref. No. of EXPLODED VIEW : P 7
GUIDE L PCB
Ref. No. of EXPLODED VIEW : P 17
DIGITAL PCB
DISASSEMBLY
3. DIGITAL PCB
and "EXPLODED VIEW"
DIGITAL PCB
Ref. No. of EXPLODED VIEW : P 13
NETWORK MODULE
Ref. No. of EXPLODED VIEW : P 20
VIDEO PCB
DISASSEMBLY
4. VIDEO PCB
and "EXPLODED VIEW"
VIDEO PCB
Ref. No. of EXPLODED VIEW : P 19
INPUT PCB
DISASSEMBLY
5. INPUT PCB
and "EXPLODED VIEW"
INPUT PCB
Ref. No. of EXPLODED VIEW : P 12
MAIN PCB
DISASSEMBLY
6. MAIN PCB
and "EXPLODED VIEW"
MAIN PCB
Ref. No. of EXPLODED VIEW : P 9
SIDE_CNT PCB
Ref. No. of EXPLODED VIEW : P 10
F_CNT PCB
Ref. No. of EXPLODED VIEW : P 11
RS232 PCB
Ref. No. of EXPLODED VIEW : P 14
RS_CNT PCB
Ref. No. of EXPLODED VIEW : P 15
SMPS PCB
DISASSEMBLY
7. SMPS PCB
and "EXPLODED VIEW"
SMPS PCB
Ref. No. of EXPLODED VIEW : P 8
