1.4. Error display
See the table below for descriptions of the displayed errors and countermeasures for these.
If multiple errors occur, only one item is displayed.
The priority order is
w
,
e
,
r
,
t
,
y
,
q
.
Condition States Display TROUBLE SHOOTING
q
Firm Check
NG
(
#
: 1/2/3/4)
The model name, brand name and region information written in the rmware are compared
to the region settings in the PCB. This error is displayed if the information does not match.
" ▲ " is displayed as the rst character if the rmware is not correct (see the illustrations on
the right).
FIRM ERROR
–
M:*************
–
Main FBL :**.**
–
DSP# :**.**
–
Audio PLD:**.**
–
Video PLD:**.**
–
GUI :********
• Check the resistor for setting the region [R1590/R1589, DIGI-
TAL PCB].
• Write the rmware for the correct region.
w
IP SCALER NG
An error occurs in Loop back Test of the DDR memory which is performed during the initial
setting of i/p Scaler(ADV8003).
IP SCALER ERR 01
• Check the circuits around the IP SCALER [IC401, DIGITAL
PCB] and DDR2 [IC402/IC403].
If there appear to be no problems, [IC401] or [IC402/IC403] is
faulty.
During the initial setting of i/p Scaler ( ADV8003 ) , there is not the reply of the Loop back Test
result of the DDR memory .
IP SCALER ERR 02
e
GUI Serial
Flash NG
If the Main CPU version is not supported by the GUI Serial Flash (ADV8003),
" ▼ " is displayed as the rst character of the GUI rmware version.
If GUI Serial Flash is damaged, " ▲ " is displayed as the rst character.
GUI VER. ERROR
•
GUI :********
–
GUI :********
• Check the rmware version.
r
DIR NG
This error is displayed if there is no response from the DIR.
DIR ERROR 01
• Check the DIR [IC202, DIGITAL PCB] and surrounding circuits.
t
DSP
#
NG
(
#
: 1/2/3/4)
Boot error 1 (After reset the DSP, DSP_Flag0 port is "Low")
DSP ERROR 01
• Check the DSP [IC251/IC261/IC271/IC281, DIGITAL PCB] and
surrounding circuits.
Boot error 2 (After reset the DSP, DSP initialization is not completed)
DSP ERROR 02
(Unused)
DSP ERROR 03
Command error 1 (After sending the command to the DSP, DSP_Flag0 port is "Low".)
DSP ERROR 04
Command error 2 (After sending the command to the DSP, MCU received "COMMAND ER-
ROR".)
DSP ERROR 05
Command error 3 (After sending the command to the DSP, MCU did not receive "COMMAND
SUCCESS".)
DSP ERROR 06
IDL error 1 (Before receiving IDL, "COMMAND BYTE" is not cleared.)
DSP ERROR 07
IDL error 2 (MCU received "IDL SERIOUS ERROR".)
DSP ERROR 08
SPI communication error
DSP ERROR 09
y
BACKUP NG
Error occurred in BACKUP. it is an error of the check sum.
BACKUP ERROR
