Explanatory Photos for DISASSEMBLY
• Fortheshootingdirectionofeachphotosusedinthismanual,seethephotobelow.
• A, B, C and Dinthephotobelowindicatetheshootingdirectionsofphotos.
• Thephotographswithnoshootingdirectionindicatedweretakenfromthetopoftheunit.
• PhotosofAVR-X4500HE3areusedinthismanual.
The viewpoint of each photograph
(Shootingdirection:X)[Viewfromthetop]
Caution:Turnupandsparewireatposition
.
Shooting direction: C
Shooting direction: D
Shooting direction: A
Shooting direction: B
Proceeding : TOP COVER FRONT ASSY
(1) Removethescrews.
(2) RemovetheSTYLEPINsandconnectors.RemovetheFFC.
Cutthewireclamps.Removethescrews.
1. FRONT ASSY
View from the bottom
x7
Shooting direction: A
x1 x1
CN602
CN321
FFC
JK433
STYLE PIN
CUT
Place the wire in this position.
STYLE PIN
