Denon AVR-X4500H Service Manual

WIRING DIAGRAM
Bridge D iod e
SMPS PCB
INLET
TUNER PACK
H EIGH T PCB PCB
MAIN T RANS
CUP12848Z
W A FER / 7 P/2m m
(P R O T .LINE)
W iFi A n te nna
W iFi A n te nna
W A FER / 2 P/7.92m m
CN902
CJP02GA89ZY
VW B 7 D 006050AG D
W IR E/6P/2.5mm/50m m
BN901
CJP40GA193ZY
CN69B
FFC W A FER/40P / 1 m m
CN321
W A FER / 5 P/2m m
CJP05GI288ZY
CN704
CJP07GA208ZY
CN781
W A FER / 6 P/2m m
(P R O T .LINE)
CJP06GA208ZY
W A FER / 6 P/2.5 m m
(D IGIT A L PO W ER )
CJP06GA353ZJ
CN903
VID EO PCB
CUP12878Z
CN951
CJP03GI289ZY
W A FER / 3 P/2.5 m m
FCC WAFER / 13P/1.25m m
CJP13GA115ZY
CN961
BN462
INPUT PCB
CUP12985Z-1
CN706 B N461
SID E CNT.PCB
CUP12921Z
W iFi A n te nna
W iFi A n te nna
CON2CON1
DIGITAL PCB
CUP12976Z
FAN_2
FAN_1
H EAT SINK
FCC CABLE
CN462
W A FER / 7 P/2m m
CJP07GI289ZY
CN461
W A FER / 9 P/2m m
CJP09GI288ZY
FRONT VFD PCB
FUNCTION ENCOD ER
VOLUME ENCODER
USB JA CK PCB
FL601
CUP12988Z-1
VW B 8 A 005400H C
UL2725# 24/# 28,1P + 2C USB
MIC
H EA DPH ON E
CUP12988Z-2
CJP40GB284ZN
CUP12985Z-2
CN69A
FFC W A FER/40P / 1 m m
CJP07GB03ZY
W A FER / 7 P/2.5 m m
CN602
W IR E/5P/2mm/ 400m m
BN321
W IR E/3P/2.5mm/350m m
(S2)
W IR E/4P/2.5mm/350m m
W IR E/5P/3.96mm/130m m
(AMP P WR)
(S1)
(S3/S4 )
(S5/S6 )
W IR E/4P/2.5mm/130m m
(FL PW R)
W IR E/2P/3.96mm/220m m
(PRI.)
LEGO MODULE
FRONT CNT . PCB
CUP12853Z
7812
7907
7805
7905 7805
7807
BN708
BN707
BN702
4CH AMP. PCB
CUP12927Z-2
5CH AMP. PCB
CUP12927Z-1
W A FER / 6 P/2.5 m m
CJP06GI289ZY
CN701
CN701
CN702
W A FER / 5 P/2.5 m m
CJP05GI289ZY
CN702
CN703
W A FER / 4 P/2.5 m m
CJP04GI289ZY
CN703
CN707
W A FER / 5 P/2.5 m m
CJP05GI289ZY
CN707
CN708
W A FER / 6 P/2.5 m m
CJP06GI289ZY
CN708
CN940
W A FER / 5 P/2.5 m m
CJP05GI289ZY
CN941
W A FER / 3 P/2.5 m m
CJP03GI289ZY
CN971
W A FER / 7 P/3.96m m
CJP07GA90ZY
CN711
W A FER / 3 P/2m m
CJP03GI352ZY
CN712
W A FER / 3 P/2m m
CJP03GI352ZY
SPK, REG. PCB
CUP12980Z-1
W AFE R/3 P /2m m
CJ P03GI288ZY
CN706
CUP12980Z-2
BN708
BN707
W IR E/6P/2.5mm/650m m
W IR E/5P/2.5mm/550m m
VW B 7 EZ055503D
BN702
W IR E/5P/2.5mm/150m m
VW B 7 E0051503D
VW B 7 EZ066503D
VW B 7 E0062803D
BN701
W IR E/6P/2.5mm/280m m
BN703
W IR E/4P/2.5mm/170m m
VW B 7 E0041703D
BN706
W IR E/3P/2mm/ 500m m
VW B 7 C 003500H C
BN461
BN462
W IR E/9P/2mm/ 450m m
W IR E/7P/2mm/ 500m m
VW B 7 B Z 07500H C
VW B 7 B 009450H C
W IRE/7 P/2mm/ 130m m
VWB7BZ07130AAC
BN704
W IRE/6 P/2mm/ 240m m
VWB7BZ06240AAC
BN781
CN711
CN712
CN971
CN940 CN941
(CNVLEGOAIOS4025)
BN951
W IR E/3P/2.5mm/50m m
VW B 1 E0030503D
ST 501
W IR E A SS'Y
ST 501
CW E5202080A
BN709
W IR E/3P/2.5mm/180m m
VW B 1 D 0031803D
CN709
W A FER / 3 P/2.5 m m
CJP03GI289ZY
FRO NT H DM I PCB
CUP12985Z-3
JK 433
H D M I W AFER
H DMI C ABLE
CUP12988Z-4
BN601A
W IR E/6P
BN601B
W IR E/6P
H /P MIC JAC K PCB
CUP12988Z-3
CN603
CUP12988Z-5
BN603
FL ATE SH IELD FRON T
WIRING DIAGRAM (AVRX4500H)
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
62

Denon AVR-X4500H Specifications

General

Display	-
Quantity	1
HDCP version	2.2
Apple docking	No
Product color	Silver
Audio decoders	DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
Audio amplifier	Yes
Multi-Zone quantity	3
Connector contacts plating	Gold
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (20-20KHz@8 Ohm)	125 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn, iHeartRadio
HDMI in	8
Audio (L/R) in	5
Composite video in	4
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	13500 g
