Proceeding : TOP COVER → FRONT ASSY → RADIATOR ASSY

(1) Removethescrews.

(2) Cutthewireclamp,thenremovetheconnector.

2. RADIATOR ASSY

View from the bottom

↑Shooting direction: B↑

↑Shooting direction: D↑

↑Shooting direction: A↑

CN462

CN708

CN707

CN701

CN702

CN703

CN461

CUT x7

CUT x1

(3) Removetheconnector.

Proceeding : TOP COVER → REAR PANEL

(1) Removethescrews.

↑Shooting direction: A↑

CN781

CN704

3. REAR PANEL

↑Shooting direction: A↑

x32

x15

Before Servicing

This Unit

Electrical Mechanical Repair Information Updating
