Denon AVR-X4500H Service Manual

RCKSK0430970 0 1 0 1 0 0 1 1 1 1 * * * * * * * * * * ZONE2 TUNING UP
RCKSK0430971 1 1 0 1 0 0 1 1 1 1 * * * * * * * * * * ZONE2 TUNING DOWN
RCKSK0430972 0 0 1 1 0 0 1 1 1 1 * * * * * * * * * * ZONE2 PRESET CH UP
RCKSK0430973 1 0 1 1 0 0 1 1 1 1 * * * * * * * * * * ZONE2 PRESET CH DOWN
RCKSK0430976 0 0 0 0 1 0 1 1 1 1 * * * * * * * * * * ZONE2 Rewind
RCKSK0430977 1 0 0 0 1 0 1 1 1 1 * * * * * * * * * * ZONE2 BAND FM
RCKSK0430978 0 1 0 0 1 0 1 1 1 1 * * * * * * * * * * ZONE2 BAND AM
RCKSK0430979 1 1 0 0 1 0 1 1 1 1 * * * * * * * * * * ZONE2 Fast Forward
RCKSK0430983 1 1 1 0 1 0 1 1 1 1 * * * * * * * * * * ZONE2 SEARCH(RDS)
RCKSK0430992 0 0 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 PLAY/PAUSE
RCKSK0430993 1 0 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 STOP
RCKSK0430994 0 1 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 PAUSE
RCKSK0430995
1 1 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 SKIP MINUS/TUNING DOWN
RCKSK0430996 0 0 1 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 SKIP PLUS/TUNING UP
RCKSK0430997 1 0 1 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 TUNING ▼
RCKSK0430998 0 1 1 0 0 1 1 1 1 1 * * * * * * * * * * ZONE2 TUNING ▲
ZONE3
REMOTE ID SET: 1
DENON CODE Parity GENRE1
GENRE2
４ ５ ２ ３ ０
4
5
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
25 26 27 28
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0
1 1 0 0
REMOTE ID SET: 2-4
DENON CODE Parity GENRE1
GENRE2
４ ５ ２ ３ ０
4
6
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
25 26 27 28
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0
0 0 1 0
No.
Data ID parity
Key Name
29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
RCKSK0450005 1 0 1 0 0 0 0 0 0 0 * * * * * * * * * * ZONE3 POWER ON/OFF
RCKSK0450006 0 1 1 0 0 0 0 0 0 0 * * * * * * * * * * ZONE3 POWER ON
RCKSK0450007 1 1 1 0 0 0 0 0 0 0 * * * * * * * * * * ZONE3 POWER OFF
RCKSK0450016 0 0 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY1
RCKSK0450017 1 0 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY2
RCKSK0450018 0 1 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY3
RCKSK0450019 1 1 0 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY4
RCKSK0450020 0 0 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY5
RCKSK0450021 1 0 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY6
RCKSK0450022 0 1 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY7
RCKSK0450023 1 1 1 0 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY8
RCKSK0450024 0 0 0 1 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY9
RCKSK0450025 1 0 0 1 1 0 0 0 0 0 * * * * * * * * * * ZONE3 KEY0
RCKSK0450027 1 1 0 1 1 0 0 0 0 0 * * * * * * * * * * ZONE3 CURSOR UP
RCKSK0450028 0 0 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE3 CURSOR DOWN
RCKSK0450029 1 0 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE3 CURSOR LEFT
RCKSK0450030 0 1 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE3 CURSOR RIGHT
RCKSK0450031 1 1 1 1 1 0 0 0 0 0 * * * * * * * * * * ZONE3 ENTER
RCKSK0450034 0 1 0 0 0 1 0 0 0 0 * * * * * * * * * * ZONE3 RETURN
RCKSK0450036 0 0 1 0 0 1 0 0 0 0 * * * * * * * * * * ZONE3 MEMORY
RCKSK0450292 0 0 1 0 0 1 0 0 1 0 * * * * * * * * * * ZONE3 QUICK SELECT 1
RCKSK0450293 1 0 1 0 0 1 0 0 1 0 * * * * * * * * * * ZONE3 QUICK SELECT 2
RCKSK0450294 0 1 1 0 0 1 0 0 1 0 * * * * * * * * * * ZONE3 QUICK SELECT 3
RCKSK0450295 1 1 1 0 0 1 0 0 1 0 * * * * * * * * * * ZONE3 QUICK SELECT 4
RCKSK0450296 0 0 0 1 0 1 0 0 1 0 * * * * * * * * * * ZONE3 QUICK SELECT 5
RCKSK0450368 0 0 0 0 1 1 1 0 1 0 * * * * * * * * * * ZONE3 VOLUME UP
RCKSK0450369 1 0 0 0 1 1 1 0 1 0 * * * * * * * * * * ZONE3 VOLUME DOWN
RCKSK0450370 0 1 0 0 1 1 1 0 1 0 * * * * * * * * * * ZONE3 VOLUME MUTE
RCKSK0450370 1 1 0 0 1 1 1 0 1 0 * * * * * * * * * * ZONE3 VR MUTE
RCKSK0450372 0 0 1 0 1 1 1 0 1 0 * * * * * * * * * * ZONE3 VR PRESET1(0dB)
RCKSK0450373 1 0 1 0 1 1 1 0 1 0 * * * * * * * * * * ZONE3 VR PRESET2(-20dB)
RCKSK0450374 0 1 1 0 1 1 1 0 1 0 * * * * * * * * * * ZONE3 VR PRESET3(-40dB)
RCKSK0450691 1 1 0 0 1 1 0 1 0 1 * * * * * * * * * * ZONE3 Internet Radio
RCKSK0450692 0 0 1 0 1 1 0 1 0 1 * * * * * * * * * * Main Zone Source CALL
RCKSK0450698 0 1 0 1 1 1 0 1 0 1 * * * * * * * * * * ZONE3 CD / PHONO
RCKSK0450699 1 1 0 1 1 1 0 1 0 1 * * * * * * * * * * ZONE3 Media Server
RCKSK0450704 0 0 0 0 0 0 1 1 0 1 * * * * * * * * * * ZONE3 PHONO
RCKSK0450705 1 0 0 0 0 0 1 1 0 1 * * * * * * * * * * ZONE3 TUNER
RCKSK0450706 0 1 0 0 0 0 1 1 0 1 * * * * * * * * * * ZONE3 CD
RCKSK0450711 1 1 1 0 0 0 1 1 0 1 * * * * * * * * * * ZONE3 HEOS MUSIC
RCKSK0450715 1 1 0 1 0 0 1 1 0 1 * * * * * * * * * * ZONE3 TUNER
RCKSK0450716 0 0 1 1 0 0 1 1 0 1 * * * * * * * * * * ZONE3 HEOS MUSIC
RCKSK0450718 0 1 1 1 0 0 1 1 0 1 * * * * * * * * * * ZONE3 USB
RCKSK0450719 1 1 1 1 0 0 1 1 0 1 * * * * * * * * * * ZONE3 FM TUNER
RCKSK0450720 0 0 0 0 1 0 1 1 0 1 * * * * * * * * * * ZONE3 DVD
RCKSK0450721 1 0 0 0 1 0 1 1 0 1 * * * * * * * * * * ZONE3 Blu-ray
RCKSK0450722 0 1 0 0 1 0 1 1 0 1 * * * * * * * * * * ZONE3 TV AUDIO
RCKSK0450723 1 1 0 0 1 0 1 1 0 1 * * * * * * * * * * ZONE3 CBL/SAT
RCKSK0450725 1 0 1 0 1 0 1 1 0 1 * * * * * * * * * * ZONE3 GAME
RCKSK0450726 0 1 1 0 1 0 1 1 0 1 * * * * * * * * * * ZONE3 MEDIA PLAYER
RCKSK0450729 1 0 0 1 1 0 1 1 0 1 * * * * * * * * * * ZONE3 AUX1
RCKSK0450730
0 1 0 1 1 0 1 1 0 1
* * * * * * * * * * ZONE3 AUX2
RCKSK0450732 0 0 1 1 1 0 1 1 0 1 * * * * * * * * * * ZONE3 DVD/Blu-ray
RCKSK0450735 1 1 1 1 1 0 1 1 0 1 * * * * * * * * * * ZONE3 MEDIA PLAYER
RCKSK0450741 1 0 1 0 0 1 1 1 0 1 * * * * * * * * * * ZONE3 INTERNET RADIO(Recent Play)
RCKSK0450751
1 1 1 1 0 1 1 1 0 1
* * * * * * * * * * ZONE3 Bluetooth
RCKSK0450787 1 1 0 0 1 0 0 0 1 1 * * * * * * * * * * ZONE3 INPUT SOURCE SELECT Right
RCKSK0450788 0 0 1 0 1 0 0 0 1 1 * * * * * * * * * * ZONE3 INPUT SOURCE SELECT Left
RCKSK0450788 0 0 1 0 0 0 1 0 1 1 * * * * * * * * * * ZONE3 SLEEP
RCKSK0450950 0 1 1 0 1 1 0 1 1 1 * * * * * * * * * * ZONE3 PAGE Previous
RCKSK0450951 1 1 1 0 1 1 0 1 1 1 * * * * * * * * * * ZONE3 PAGE Next
RCKSK0450956 0 0 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE3 REPEAT
RCKSK0450957 1 0 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE3 RANDOM/SHUFFLE
RCKSK0450958 0 1 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE3 USB DIRECT PLAY
RCKSK0450959 1 1 1 1 1 1 0 1 1 1 * * * * * * * * * * ZONE3 FAVORITE DIRECT PLAY
RCKSK0450970 0 1 0 1 0 0 1 1 1 1 * * * * * * * * * * ZONE3 TUNING UP
RCKSK0450971 1 1 0 1 0 0 1 1 1 1 * * * * * * * * * * ZONE3 TUNING DOWN
RCKSK0450972 0 0 1 1 0 0 1 1 1 1 * * * * * * * * * * ZONE3 PRESET CH UP
RCKSK0450973 1 0 1 1 0 0 1 1 1 1 * * * * * * * * * * ZONE3 PRESET CH DOWN
RCKSK0450976 0 0 0 0 1 0 1 1 1 1 * * * * * * * * * * ZONE3 Rewind
RCKSK0450977 1 0 0 0 1 0 1 1 1 1 * * * * * * * * * * ZONE3 BAND FM
RCKSK0450978 0 1 0 0 1 0 1 1 1 1 * * * * * * * * * * ZONE3 BAND AM
RCKSK0450979 1 1 0 0 1 0 1 1 1 1 * * * * * * * * * * ZONE3 Fast Forward
RCKSK0450983 1 1 1 0 1 0 1 1 1 1 * * * * * * * * * * ZONE3 SEARCH(RDS)
RCKSK0450992 0 0 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE3 PLAY/PAUSE
RCKSK0450993 1 0 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE3 STOP
RCKSK0450994 0 1 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE3 PAUSE
RCKSK0450995
1 1 0 0 0 1 1 1 1 1 * * * * * * * * * * ZONE3 SKIP MINUS/TUNING DOWN
RCKSK0450996 0 0 1 0 0 1 1 1 1 1 * * * * * * * * * * ZONE3 SKIP PLUS/TUNING UP
RCKSK0450997 1 0 1 0 0 1 1 1 1 1 * * * * * * * * * * ZONE3 TUNING ▼
RCKSK0450998 0 1 1 0 0 1 1 1 1 1 * * * * * * * * * * ZONE3 TUNING ▲
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
78

Denon AVR-X4500H Specifications

General

Display	-
Quantity	1
HDCP version	2.2
Apple docking	No
Product color	Silver
Audio decoders	DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
Audio amplifier	Yes
Multi-Zone quantity	3
Connector contacts plating	Gold
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (20-20KHz@8 Ohm)	125 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn, iHeartRadio
HDMI in	8
Audio (L/R) in	5
Composite video in	4
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	13500 g
