Denon AVR-X4500H Service Manual

PACKAGING VIEW
Parts List :
http://dmedia.dmglobal.com/Document/DocumentDetails/24820
'H' TAPING
1
2
3
4
5
6
4
'I' TAPING
[AVRX4500HBKE3/AVRX4500HBKE2/AVRX4500HSPE2]
[AVRX4500HK][AVRX4500HBKE1C]
CONTROL LABEL
CONTROL LABELCONTROL LABEL
[AVRX4500HBKE3] [AVRX4500HBKE2]
[AVRX4500HSPE2]
[AVRX4500HK]
[AVRX4500HBKE1C]
[E3 / E2 Ver.] [K / E1C Ver.]
4
7
6
21
1
2
3
26
23
28
5
8
9
11
10
7
13
12
14
17
15
16
3
18
18-1
18
18-1
18
18-2
18-1
29
18-3 18-2
18
18
20
18
1818
18-4
29
29
21
24
26
22
22
25
25
27
24
26
25
18
18
19
19
25
21
21
25
25
25
30
UK plug
(UK Only)
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
87

Denon AVR-X4500H Specifications

General

Display	-
Quantity	1
HDCP version	2.2
Apple docking	No
Product color	Silver
Audio decoders	DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Volume control	Rotary
Audio amplifier	Yes
Multi-Zone quantity	3
Connector contacts plating	Gold
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (20-20KHz@8 Ohm)	125 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, TuneIn, iHeartRadio
HDMI in	8
Audio (L/R) in	5
Composite video in	4
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	13500 g
