n About the speaker cable label
(supplied) for channel identification.
The channel display section for speaker terminals on
the rear panel is color-coded for each channel to be
identifiable.
Attach the speaker cable label for each channel to its
speaker cable as shown in the diagram.
Then, make connection so that the color of the speaker
terminal matches that of the speaker cable label.
Speaker This unit
n Connecting the speaker cables.
Approx. 10 mm
