General| Channels | 5.2 |
|---|---|
| HDMI Inputs | 5 |
| HDMI Outputs | 1 |
| Bluetooth | Yes |
| 4K Ultra HD Pass-through | Yes |
| Dolby TrueHD | Yes |
| DTS-HD Master Audio | Yes |
| Auto Speaker Calibration | No |
| Number of Power Amps | 5 |
| Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive) | 90 W |
| Output Power (6 ohm, 1 kHz, 10% 1ch Drive) | 140 W |
| Composite In | 2 |
| Composite Out | 1 |
| Digital In: Optical | 2 |
| Analog In | 2 |
| Speaker Terminal: Screw | Yes |
| FM Tuner with RDS | Yes |
| 3D Signal Pass-Through | Yes |
| Audio Return Channel | Yes |
| HDMI Standby Pass-Through | Yes |
| CEC | Yes |
| Auto Speaker Setup by Microphone | No |
| Dimensions (W x H x D) | 434 x 151 x 319 mm |
| Weight | 7.5 kg |
| Total Harmonic Distortion | 0.08 % |
| Input Sensitivity/Impedance | 200 mV / 47 kΩ |
| Signal-to-Noise Ratio | 98 dB |
| Ethernet Port | No |
| Wi-Fi | No |
| Power Output per Channel | 70W (8 ohms, 20Hz - 20kHz, 0.08% THD) |
| Frequency Response | 10Hz - 100kHz |
| Supported Audio Formats | MP3, WMA, AAC |
