Denon AVR-X540BT Service Manual

1. Version Display Mode
1.1. Actions
Version information is displayed when the device is started in this mode.
1.2. Starting up
AVR-S530BT
· While holding down buttons "
TUNER PRESET CH+
" and "
TUNE -
" simultaneously, press the power
button to turn on the power.
AVR-X540BT
· While holding down buttons "
TUNE +
" and "
DIMMER
" simultaneously, press the power button to
turn on the power.
then press the "
STATUS
" button to display the information in section 1.3 on the display.
1.3. Display Order
Error information(See "1.4. Error display") →
q
Model destination information
→
w
Main µ-com →
e
Main IAP →
r
DSP version →
t
OSD version →
y
USB version
q
Model destination information :
AVR-S530 E3 *
AVR-X540 \\\ *
\
: Region (E3, E2, E1C)
w
Main µ-com :
Main :**.**
e
Main IAP :
Main IAP V**.**
r
DSP version :
DSP.*.*.*
t
OSD version :
OSD :**.**
y
USB version :
USB.**.**.**
1.4. Error display
See the table below for descriptions of the displayed errors and countermeasures for these.
If multiple errors occur, only one item is displayed.
Condition
States Display
DSP NG Cannot execute DSP reset in DSP code boot.
DSP ERROR 01
DSP OK - (No Error display)
67
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
