POWER

POWER PCB ASS'Y

※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view.

※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.

NOTE:The symbols in the column Remarks indicate the following destinations.

E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model

BK : Black model SP : Premium Silver model

REF No. Part No. Part Name Remarks Q'ty New Ver

SEMICONDUCTORS GROUP

D3001 943203500730S DIODE, RECTIFIER, AXIAL CVD1N4007SL 1

D3002 943203500730S DIODE, RECTIFIER, AXIAL CVD1N4007SL 1

D3003 943203500730S DIODE, RECTIFIER, AXIAL CVD1N4007SL 1

D3004 943203500730S DIODE, RECTIFIER, AXIAL CVD1N4007SL 1

D3103 00D9430182609 DIODE , SWITCHING CVD1SS133MT 1

D3104 00D9430182609 DIODE , SWITCHING CVD1SS133MT 1

D6001 943203500730S DIODE, RECTIFIER, AXIAL CVD1N4007SL 1

D6002 943203500730S DIODE, RECTIFIER, AXIAL CVD1N4007SL 1

D6003 943203500730S DIODE, RECTIFIER, AXIAL CVD1N4007SL 1

D6004 943203500730S DIODE, RECTIFIER, AXIAL CVD1N4007SL 1

D6005 943203500730S DIODE, RECTIFIER, AXIAL CVD1N4007SL 1

D6006 943203500730S DIODE, RECTIFIER, AXIAL CVD1N4007SL 1

D6007 943203500730S DIODE, RECTIFIER, AXIAL CVD1N4007SL 1

D6008 943203500730S DIODE, RECTIFIER, AXIAL CVD1N4007SL 1

D6009 00D9430182609 DIODE , SWITCHING CVD1SS133MT 1

D6012 943203500730S DIODE, RECTIFIER, AXIAL CVD1N4007SL 1

D6013 943204500310S DIODE , Schottky Battier (TO220FN) CVDRBQ30T65A 1

IC301 943232100370S I.C,REGULATOR(+12V,TO220) CVIKIA7812BPI 1

IC302 00D9430183909 I.C , REGULATOR HVIKIA7912PI 1

IC305 943231010390S I.C,REGULATOR(+5V,T0220IS) CVIKIA7805BPI 1

IC601 943231102160S I.C , OFF-LINE POWER SWITCH CVITOP268VG 1

! IC602 963239010480S I.C , PHOTOCOUPLER CVIPC123Y22FZ0F 1

IC603 212050010508S I.C,SHUNT REGULATOR(TO-92) CVIKIA2431AP 1

IC604 943239100730S I.C , SYSTEM RESET(4.8V , SOT-25A) CVIPST8448NR_A 1

Q6002 943222500440S F.E.T , 2N7002KA, N-CH, SOT-23, KEC CVT2N7002KA 1 *

Q6003 943214500020S T.R,2SC3052 CVT2SC3052 1

ZD601 943202501140S DIODE, ZENER, 1/2W, 12V CVDZJ12BL 1

ZD608 943202501120S DIODE, ZENER, 1/2W, 39V E3 CVDZJ39BL 1

ZD609 943202501120S DIODE, ZENER, 1/2W, 39V E3 CVDZJ39BL 1

ZD610 943202501120S DIODE, ZENER, 1/2W, 39V E3 CVDZJ39BL 1

ZD611 943202501170S DIODE, ZENER, 1/2W, 22V CVDZJ22BL 1

ZD612 943202501170S DIODE, ZENER, 1/2W, 22V CVDZJ22BL 1

ZD613 943202501170S DIODE, ZENER, 1/2W, 22V CVDZJ22BL 1

ZD614 943202501170S DIODE, ZENER, 1/2W, 22V CVDZJ22BL 1

ZD615 943202501170S DIODE, ZENER, 1/2W, 22V CVDZJ22BL 1

ZD616 943202501170S DIODE, ZENER, 1/2W, 22V CVDZJ22BL 1

ZD617 943202501170S DIODE, ZENER, 1/2W, 22V CVDZJ22BL 1

ZD618 943202501160S DIODE, ZENER, 1/2W, 27V CVDZJ27BL 1

ZD619 943202501110S DIODE, ZENER, 1/2W, 6.8V CVDZJ6V8BL 1

ZD620 943202501120S DIODE, ZENER, 1/2W, 39V CVDZJ39BL 1

ZD621 943202501200S DIODE, ZENER, 1/2W, 7.5V E3 CVDZJ7V5BL 1

ZD621 943202501180S DIODE, ZENER, 1/2W, 16V E2,E1C CVDZJ16BL 1

RESISTOR GROUP

R6004 nsp RES, CARBON(1/5W,330Kohm,J) CRD20TJ334T 1

R6006 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1

R6008 nsp RES, CARBON(1/5W,2.2Mohm,J) E3 CRD20TJ225T 1

R6009 nsp RES, CARBON(1/5W,2.2Mohm,J) E3 CRD20TJ225T 1

R6010 nsp RES, CARBON(1/5W,1Mohm,J) E3 CRD20TJ105T 1

R6011 nsp RES, CHIP(1608/5%/10ohm) CRJ10DJ100T 1

R6012 nsp RES, CHIP(1608/5%/270Kohm) E3 CRJ10DJ274T 1

R6012 nsp RES, CHIP(1608/5%/56Kohm) E2,E1C CRJ10DJ563T 1

R6013 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ223T 1

R6014 nsp RES, CHIP(1608/5%/1Kohm) E3 CRJ10DJ102T 1

R6014 nsp RES, CHIP(1608/5%/3Kohm) E2,E1C CRJ10DJ302T 1

R6015 nsp RES, CARBON(1/5W,6.8ohm,J) CRD20TJ6R8T 1

R6016 nsp RES, CARBON(1/5W,56ohm,J) CRD20TJ560T 1

R6017 nsp RES, CARBON(1/5W,3.3Kohm,J) CRD20TJ332T 1

R6018 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1

R6019 nsp RES, CHIP(1608/1%/22Kohm) CRJ10DF2202T 1

R6022 nsp RES, CHIP(1608/1%/6.8Kohm) CRJ10DF6801T

R6024 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R6025 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1

R6027 nsp RES, CHIP(2012/5%/8.2Mohm) CRJ18AJ825T 1

R6028 nsp RES, CHIP(2012/5%/8.2Mohm) CRJ18AJ825T 1

R6029 nsp RES, CHIP(2012/5%/8.2Mohm) CRJ18AJ825T 1

R6030 nsp RES, CHIP(2012/5%/8.2Mohm) CRJ18AJ825T 1

R6031 nsp RES, CHIP(2012/5%/1Mohm) CRJ18AJ105T 1

R6032 nsp RES, CHIP(2012/5%/1Mohm) CRJ18AJ105T 1

R6033 nsp RES, CHIP(2012/5%/1Mohm) CRJ18AJ105T 1

CAPACIITORS GROUP

C3005 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1

C3006 943134010620S CAP, ELECT(25V/4700uF) CCEA1EH472E 1

C3007 00MOA33802520 CAP, ELECT(25V/3300uF) CCEA1EH332E 1

C3008 943134502350S CAP, ELECT(50V/470uF) CCEA1HH471E 1

C3012 943134502350S CAP, ELECT(50V/470uF) CCEA1HH471E 1

C3013 943134502350S CAP, ELECT(50V/470uF) CCEA1HH471E 1

! C6001 943132100820S CAP, CERAMIC(X1/Y1, 0.01uF, AC250V) CCKDCT103MF 1 *

! C6002 943132100820S CAP, CERAMIC(X1/Y1, 0.01uF, AC250V) CCKDCT103MF 1 *

! C6003 943132100820S CAP, CERAMIC(X1/Y1, 0.01uF, AC250V) CCKDCT103MF 1 *

C6004 943134501590S CAP, ELECT(200V/100uF),105'C E3 CCET200NHA101ES 1

C6004 963134010200S CAP , ELECT (400V/100UF, 18X40, NHA) E2,E1C CCET400NHA101ES 1

C6007 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6008 00D9430175108 CAP, ELECT(50V/10uF),105'C CCEA1HNXA100TS 1

C6009 nsp CAP, CHIP(1608, 50V/0.22uF, X5R)_SAMSUNG CCUS1H224KCS 1

C6011 943132100640S CAP, CHIP(3216, 1000pF, DC1KV, MURATA GRM31) CCUMUP3A102JAM 1

C6012 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6013 00MOA47602520 CAP, ELECT(25V/47uF),105'C CCEA1ENXA470TS 1

C6014 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6015 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CCUS0J475KCS 1

C6018 963134010220S CAP, ELECT(6.3V/5600uF) CCEA0JNXA562ES 1

C6019 963134010220S CAP, ELECT(6.3V/5600uF) CCEA0JNXA562ES 1

C6020 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6021 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

! C6023 943132100810S CAP, CERAMIC(X1/Y1, 2200pF, AC400V) CCKDCT222ME 1 *

C6024 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6026 943139500110S CAP, CHIP(3216, 1KV/47pF, C0G)_SAMSUNG CCUP3A470JAS 1

C6029 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6030 nsp CAP, CHIP(1608, 50V/0.015uF, X7R)_SAMSUNG CCUS1H153KCS 1

OTHER PARTS GROUP

BK301 nsp BRACKET , PCB CMD1A569-V1 1

BK303 nsp BRACKET , PCB CMD1A387-V1 1

BK601 nsp BRACKET , PCB M3 CMD1A834 1

BK602 nsp BRACKET , PCB M3 CMD1A834 1

BK603 nsp BRACKET , PCB CMD1A629 1

BN301 nsp WIRE ASS'Y Locking (YH( (5P,2MM,130MM,#24) VWB1C005130HC 1 *

BN601 nsp WIRE ASS'Y (YH-CKM) (6P,2.5MM,220MM,#22) VWB1D006220BD 1 *

CN302 nsp WAFER/STRAIGHT/2.5mm/5P CJP05GA01ZY 1

CN601 nsp WAFER, 2P, 3.96mm CJP02KA060ZY 1

CN602 nsp WAFER, 2P, 7.92mm CJP02GA89ZY 1

! CX601 943139500020S CAP , POLYPROPYLENE FILM HCQF2E104KZE 1

! CY601 943132100800S CAP, CERAMIC(X1/Y1, 470pF, AC400V) CCKDCT471KB 1 *
