Denon AVR-X540BT Service Manual

POWER
REF No. Part No. Part Name Remarks Q'ty New Ver
! CY602 943132100800S CAP, CERAMIC(X1/Y1, 470pF, AC400V) CCKDCT471KB 1 *
! F3003 943652500510D FUSE(932Series, 250V/1.25A) CBA2J1250TLEBT 1
! F3004 943652500510D FUSE(932Series, 250V/1.25A) CBA2J1250TLEBT 1
! F6001 963652010510S FUSE(S506 Series, 250V,2A) E3 CBA2C2000TLEC 1
! F6001 963652010500S FUSE(S506 Series, 250V,1.6A) E2,E1C CBA2C1600TLEC 1
F6001 nsp HOLDER , FUSE KJCFC5S 2
! F6002 0520100170060 FUSE(218Series, 250V/5A) E3 KBA2C5000TLEY 1
! F6002 00D9430199109 FUSE(218Series, 250V/2.5A) E2,E1C KBA2C2500TLEY 1
F6002 nsp HOLDER , FUSE KJCFC5S 2
L6001 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
! LF602 963111010230S LINE FILTER, 27mH E3 CLZ9Z126Z 1
! LF602 943111100410S LINE FILTER, 50mH E2,E1C CLZ9Z133Z 1
! RY601 963682010370S RELAY,HL31-1AT-5H,DC5V,1C1P CSL1C006ZE 1
T6001 943102100720S TRANS, SWITCHING VLT9Z132ZW 1
11

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
