DIGITAL

DIGITAL PCB ASS'Y

※Parts indicated by "nsp"on this table cannot be supplied. Part indicated by "@" mark is not illustrated in the exploded view.

※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.

NOTE:The symbols in the column Remarks indicate the following destinations.

E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model

BK : Black model SP : Premium Silver model

REF No. Part No. Part Name Remarks Q'ty New Ver

SEMICONDUCTORS GROUP

D7102 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1

D7105 943202501230S DIODE, ZENER(5.1V/0.5W, SOD-123) CVDMM1Z525V1B 1

D7106 943202501230S DIODE, ZENER(5.1V/0.5W, SOD-123) CVDMM1Z525V1B 1

D7501 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1

D7502 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1

D7601 943202501530S DIODE , ZENER(7.5V/0.5W, SOD-323HE) CVDTFZV7.5B 1 *

D7602 943202501530S DIODE , ZENER(7.5V/0.5W, SOD-323HE) CVDTFZV7.5B 1 *

D7605 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1

D7606 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1

D7607 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1

D7608 943202501210S DIODE, ZENER(3.6V/0.5W, SOD-123) CVDMM1Z523V6B 1

IC711 943243103500S

I.C, MAIN MCU(AVRS530BT,AVRX540BT)

See PROCEDURE AFTER REPLACING THE U-COM, ETC.

VVIANAM2403AV 1 *

IC712 943246010440S I.C , EEPROM (32 Kbit) ST CVIM24C32WMN6TP 1

IC721 943236012460S I.C , HDMI Transceiver (LQFP-144P) CVIADV7623BSTZ 1

IC722 943248104000S

I.C, OSD(AVRS530BT,AVRX540BT)

See PROCEDURE AFTER REPLACING THE U-COM, ETC.

VVIANAM2404AV 1 *

IC731 23681050460AS I.C , HDMI 2.0 Transceiver (HQFP-144P) CVIMN864788 1

IC741 943245010410S EOL item I.C , DSP (CIRRUS LOGIC) CVICS497024CVZ 1

IC742 943245100940S

I.C, DSP(AVRS530BT,AVRX540BT)

See PROCEDURE AFTER REPLACING THE U-COM, ETC.

VVIANAM2405AV 1 *

IC743 943236101210S I.C, 16MB SDRAM(TSOP-50P)

CVIM12L16161A5TG2Q 1

IC744 90M-HC110090R I.C , CODEC + DIR (CIRRUS LOGIC) HVICS42528-CQ 1

IC745 00D2623198902 I.C, QUAD 2-CHANNEL MUX(TSSOP-16) HVITC74VHC157FT 1

IC751 943239101860S I.C , DC-DC CONVERTER(SOT-23) CVITPS563200DDCR 1

IC752 943239101860S I.C , DC-DC CONVERTER(SOT-23) CVITPS563200DDCR 1

IC753 943239101860S I.C , DC-DC CONVERTER(SOT-23) CVITPS563200DDCR 1

IC756 943239010400S I.C, REGULATOR(3.3V/TO-252) CVINJM2845DL133 1

IC761 943235100520S I.C , INPUT WITH 8CH VOLUME(52P LQFP) CVINJU72340AFH3 1

IC762 943232100380S I.C , DUAL OPAMP(SOP-8P) CVINJM8080G 1

IC763 943232100380S I.C , DUAL OPAMP(SOP-8P) CVINJM8080G 1

IC764 943232100380S I.C , DUAL OPAMP(SOP-8P) CVINJM8080G 1

IC766 00MHC10172090 I.C , OP AMP HVINJM2115MTE1 1

IC767 00MHC10172090 I.C , OP AMP HVINJM2115MTE1 1

Q7105 943214500020S T.R,2SC3052 CVT2SC3052 1

Q7106 943214500020S T.R,2SC3052 CVT2SC3052 1

Q7107 943214500020S T.R,2SC3052 CVT2SC3052 1

Q7108 943214500020S T.R,2SC3052 CVT2SC3052 1

Q7109 963212500030S T.R, ISA1530AC1 CVTISA1530AC1 1

Q7110 943214500020S T.R,2SC3052 CVT2SC3052 1

Q7111 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 1

Q7112 943214500020S T.R,2SC3052 CVT2SC3052 1

Q7113 943214500020S T.R,2SC3052 CVT2SC3052 1

Q7201 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q7202 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q7203 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q7204 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q7205 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q7206 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q7301 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q7302 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q7303 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q7304 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q7501 943219500200M T.R , CHIP , SOT-23 HVTKRC104S 1

Q7502 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1

Q7503 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1

Q7504 943219500200M T.R , CHIP , SOT-23 HVTKRC104S 1

Q7505 943219500200M T.R , CHIP , SOT-23 HVTKRC104S 1

Q7506 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1

Q7509 943219500200M T.R , CHIP , SOT-23 HVTKRC104S 1

Q7510 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1

Q7512 943214500020S T.R,2SC3052 CVT2SC3052 1

Q7515 963212500030S T.R, ISA1530AC1 CVTISA1530AC1 1

Q7516 00D2690192902 T.R , CHIP , SOT-23 HVTKRC102S 1

Q7517 943219500200M T.R , CHIP , SOT-23 HVTKRC104S 1

Q7518 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1

Q7519 943219500200M T.R , CHIP , SOT-23 HVTKRC104S 1

Q7520 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1

Q7521 943219500200M T.R , CHIP , SOT-23 HVTKRC104S 1

Q7522 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1

Q7610 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 1

Q7612 00D2690191903 T.R , CHIP , SOT-23 HVTKRA104S 1

Q7613 943219500200M T.R , CHIP , SOT-23 HVTKRC104S 1

Q7614 00D2690191903 T.R , CHIP , SOT-23 HVTKRA104S

RESISTOR GROUP

R7101 nsp RES, CHIP(1005/5%/470Kohm) CRJ06IJ474T 1

R7102 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1

R7103 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1

R7104 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1

R7107 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1

R7108 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R7113 nsp RES, CHIP(1608/5%/4.7Kohm) E3 CRJ10DJ472T 1

R7113 nsp RES, CHIP(1608/5%/10Kohm) E1C CRJ10DJ103T 1

R7114 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R7115 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1

R7116 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1

R7127 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1

R7129 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1

R7136 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1

R7137 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1

R7138 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R7139 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1

R7143 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1

R7144 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1

R7145 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ223T 1

R7147 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ223T 1

R7148 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ223T 1

R7149 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R7150 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R7151 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R7152 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1

R7153 nsp RES, CHIP(1005/5%/2.7Kohm) CRJ06IJ272T 1

R7154 nsp RES, CHIP(1005/5%/2.7Kohm) CRJ06IJ272T 1

R7155 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1

R7156 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1

R7157 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1

R7159 nsp RES, CHIP(1608/5%/120Kohm) CRJ10DJ124T 1

R7160 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1

R7162 nsp RES, CHIP(1608/5%/120Kohm) CRJ10DJ124T 1

R7163 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1

R7164 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
