Denon AVR-X540BT Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q'ty New Ver
R7165 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7166 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R7167 nsp RES, CHIP(1005/5%/100Kohm) CRJ06IJ104T 1
R7168 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R7170 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7171 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7172 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7173 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7174 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7175 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7176 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7177 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7178 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7179 nsp RES, CHIP(1005/5%/100Kohm) CRJ06IJ104T 1
R7180 nsp RES, CHIP(1005/5%/2.2Mohm) CRJ06IJ225T 1
R7181 nsp RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R7182 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7183 nsp RES, CHIP(1005/5%/100Kohm) CRJ06IJ104T 1
R7184 nsp RES, CHIP(1005/5%/220Kohm) CRJ06IJ224T 1
R7185 nsp RES, CHIP(1005/5%/27Kohm) CRJ06IJ273T 1
R7186 nsp RES, CHIP(1005/5%/1.2Kohm) CRJ06IJ122T 1
R7187 nsp RES, CHIP(1005/5%/3.3Kohm) CRJ06IJ332T 1
R7188 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7190 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7191 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7192 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7195 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7196 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7201 nsp RES, CHIP(1608/1%/1.6Kohm) CRJ10DF1601T 1
R7202 nsp RES, CHIP(1608/1%/2Kohm) CRJ10DF2001T 1
R7203 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7204 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7206 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7208 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7210 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7211 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7212 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7213 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7214 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7215 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7216 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7218 nsp RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R7219 nsp RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R7220 nsp RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R7221 nsp RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R7222 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7224 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7228 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7231 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7232 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7233 nsp RES, CHIP(1005/5%/100ohm)
CRJ06IJ101T 1
R7234
nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7235 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7236 nsp RES, CHIP(1005/5%/1.8Kohm) CRJ06IJ182T 1
R7237 nsp RES, CHIP(1005/5%/1.8Kohm) CRJ06IJ182T 1
R7238 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7239 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7240 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7241 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7242 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7243 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7244 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7245 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7246 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7247 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7248 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7250 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7251 nsp RES, CHIP(1608/5%/390Kohm) CRJ10DJ394T 1
R7252 nsp RES, CHIP(1005/1%/1Kohm) CRJ06IF1001T 1
R7253 nsp RES, CHIP(1005/1%/1Kohm) CRJ06IF1001T 1
R7254 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7255 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7256 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7257 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7258 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7259 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7260 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7261 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7262 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7263 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7264 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7265 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7266 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7267 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7268 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7269 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7270 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7271 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7272 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7273 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7274 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7275 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7276 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7277 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7278 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7279 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7280 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7281 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7282 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7283 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7285 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7286 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T
1
R7287 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7289 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7291 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7292 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7295 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7296 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7301 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7302 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7303 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7304 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7305 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7306 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7307 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7308 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7311 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7312 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7313 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
13

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
