Denon AVR-X540BT Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q'ty New Ver
R7314 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7315 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7316 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7317 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7318 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7325 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7333 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7334 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7335 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7336 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7337 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7338 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7339 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7340 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7341 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7342 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7343 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R7344 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R7345 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R7346 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7347 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7348 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7349 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7350 nsp RES, CHIP(1005/5%/1Mohm) CRJ06IJ105T 1
R7351 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7352 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7354 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7356 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R7360 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7361 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7362 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7363 nsp RES, CHIP(1005/5%/2Kohm) CRJ06IJ202T 1
R7364 nsp RES, CHIP(1005/5%/2Kohm) CRJ06IJ202T 1
R7365 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7366 nsp RES, CHIP(1608/1%/51ohm) CRJ10DF51R0T 1
R7367 nsp RES, CHIP(1608/1%/51ohm) CRJ10DF51R0T 1
R7368 nsp RES, CHIP(1005/5%/6.8Kohm) CRJ06IJ682T 1
R7370 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7371 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7372 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7392 nsp RES, CHIP(1005/5%/1.8Kohm) CRJ06IJ182T 1
R7393 nsp RES, CHIP(1005/5%/1.8Kohm) CRJ06IJ182T 1
R7401 nsp RES, CHIP(1005/5%/3.3Kohm) CRJ06IJ332T 1
R7402 nsp RES, CHIP(1005/5%/330ohm) CRJ06IJ331T 1
R7403 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R7404 nsp RES, CHIP(1608/1%/5.1Kohm) CRJ10DF5101T 1
R7405 nsp RES, CHIP(1005/5%/3.3Kohm) CRJ06IJ332T 1
R7406 nsp RES, CHIP(1005/5%/3.3Kohm) CRJ06IJ332T 1
R7407 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7408 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7412 nsp RES, CHIP(1608/1%/1.37Kohm)
CRJ10DF1371T 1
R7413
nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7414 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7415 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7416 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7417 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7418 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7419 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7420 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7422 nsp RES, CHIP(1005/5%/3.3Kohm) CRJ06IJ332T 1
R7423 nsp RES, CHIP(1005/5%/3.3Kohm) CRJ06IJ332T 1
R7424 nsp RES, CHIP(1005/5%/3.3Kohm) CRJ06IJ332T 1
R7425 nsp RES, CHIP(1005/5%/3.3Kohm) CRJ06IJ332T 1
R7426 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7427 nsp RES, CHIP(1005/5%/3.3Kohm) CRJ06IJ332T 1
R7428 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7429 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7430 nsp RES, CHIP(1005/5%/75ohm) CRJ06IJ750T 1
R7431 nsp RES, CHIP(1005/5%/68ohm) CRJ06IJ680T 1
R7432 nsp RES, CHIP(1005/5%/68ohm) CRJ06IJ680T 1
R7443 nsp RES, CHIP(1005/5%/68ohm) CRJ06IJ680T 1
R7444 nsp RES, CHIP(1005/5%/68ohm) CRJ06IJ680T 1
R7445 nsp RES, CHIP(1005/5%/68ohm) CRJ06IJ680T 1
R7446 nsp RES, CHIP(1005/5%/68ohm) CRJ06IJ680T 1
R7447 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7448 nsp RES, CHIP(1005/5%/68ohm) CRJ06IJ680T 1
R7449 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7450 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7471 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7472 nsp RES, CHIP(1005/5%/220ohm) CRJ06IJ221T 1
R7473 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7474 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R7475 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7476 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7477 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7478 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7482 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7483 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7484 nsp RES, CHIP(1005/5%/68ohm) CRJ06IJ680T 1
R7501 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7502 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7504 nsp RES, CHIP(1608/1%/10Kohm) CRJ10DF1002T 1
R7505 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7506 nsp RES, CHIP(1608/1%/33.2Kohm) CRJ10DF3322T 1
R7507 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7508 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7509 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7511 nsp RES, CHIP(1608/1%/10Kohm) CRJ10DF1002T 1
R7512 nsp RES, CHIP(1608/1%/4.7Kohm) CRJ10DF4701T 1
R7513 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7514 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R7515 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T
1
R7517 nsp RES, CHIP(1608/1%/10Kohm) CRJ10DF1002T 1
R7518 nsp RES, CHIP(1608/1%/13.7Kohm) CRJ10DF1372T 1
R7519 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7520 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7524 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7525 nsp RES, CHIP(1005/5%/33Kohm) CRJ06IJ333T 1
R7526 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7527 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7529 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7530 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7533 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7534 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7542 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7543 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7544 nsp RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R7545 nsp RES, CHIP(1005/5%/100Kohm) CRJ06IJ104T 1
R7546 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
14

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
