Denon AVR-X540BT Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q'ty New Ver
R7547 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R7550 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7551 nsp RES, CHIP(1005/5%/3.3Kohm) CRJ06IJ332T 1
R7552 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7553 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7554 nsp RES, CHIP(1005/5%/33Kohm) CRJ06IJ333T 1
R7555 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7556 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7557 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7558 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7561 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7601 nsp RES, CHIP(1608/5%/270ohm) CRJ10DJ271T 1
R7602 nsp RES, CHIP(1608/5%/270ohm) CRJ10DJ271T 1
R7603 nsp RES, CHIP(1608/5%/27Kohm) CRJ10DJ273T 1
R7604 nsp RES, CHIP(1608/5%/27Kohm) CRJ10DJ273T 1
R7605 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7606 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7608 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7611 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7614 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R7615 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7616 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7617 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R7618 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R7619 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7620 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7621 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R7622 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R7623 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7624 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7625 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7626 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7627 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7633 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7634 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7637 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7638 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7639 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7640 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7647 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R7648 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R7649 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R7650 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7651 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7652 nsp RES, CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R7653 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7655 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7656 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7657 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R7664 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7665 nsp RES, CHIP(1608/5%/470ohm)
CRJ10DJ471T 1
R7666
nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7667 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7668 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R7670 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 1
R7671 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 1
R7672 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 1
R7673 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 1
R7674 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7675 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7676 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7677 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7678 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7679 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7680 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7681 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7682 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7683 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7686 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 1
R7687 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 1
R7688 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 1
R7689 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 1
R7690 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7691 nsp RES, CHIP(1608/0.5%/8.2Kohm) CRJ06DD822TP 1
R7692 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7693 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7694 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7695 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7696 nsp RES, CHIP(1608/0.5%/8.2Kohm) CRJ06DD822TP 1
R7697 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7698 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7699 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7702 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 1
R7703 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 1
R7704 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 1
R7705 nsp RES, CHIP(1608/0.5%/2.4Kohm) CRJ06DD242TP 1
R7706 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7707 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7708 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7709 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7710 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7711 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7712 nsp RES, CHIP(1608/0.5%/3Kohm) CRJ06DD302TP 1
R7713 nsp RES, CHIP(1608/5%/2Kohm) CRJ10DJ202T 1
R7714 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7715 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7718 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7719 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7723 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7724 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7725 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7726 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T
1
R7727 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7729 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R7730 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7732 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R7736 nsp RES , CHIP(6432/5%/150ohm/1W) CRJ01HJ151T 1
R7737 nsp RES , CHIP(6432/5%/150ohm/1W) CRJ01HJ151T 1
R7738 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7741 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7742 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R7744 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7745 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7747 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7748 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7752 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7753 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7754 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R7755 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
15

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
