Denon AVR-X540BT Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q'ty New Ver
R7756 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R7757 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R7758 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7762 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7763 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R7774 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7775 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7776 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7777 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7778 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7779 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7781 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R7811 nsp RES, CHIP(1005/5%/75ohm) E3 CRJ06IJ750T 1
RN711 nsp RES, CHIP(1005/5%/100ohm*4) CRJ064IJ101T 1
RN712 nsp RES, CHIP(1005/5%/100ohm*4) CRJ064IJ101T 1
RN731 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
RN732 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
RN733 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
RN734 943113100000S COMMON MODE FILTER (1210, 90ohm) CLZ9Z188Z 1
RN735 nsp RES, CHIP(1005/5%/10ohm*4) CRJ064IJ100T 1
RN741 nsp RES, CHIP(1005/5%/10Kohm*4) CRJ064IJ103T 1
RN742 nsp RES, CHIP(1005/5%/10Kohm*4) CRJ064IJ103T 1
RN743 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN744 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN745 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN746 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN747 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN748 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN749 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN750 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN751 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
CAPACIITORS GROUP
C7101 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7102 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7103 nsp CAP, CHIP(1608, 50V/20pF, C0G)_SAMSUNG CCUS1H200JAS 1
C7104 nsp CAP, CHIP(1608, 50V/20pF, C0G)_SAMSUNG CCUS1H200JAS 1
C7105 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7106 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7110 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7111 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7112 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7113 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7114 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7115 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7116 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7117 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7118 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7119 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7120 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7121 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7124 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7125 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7126 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7127 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7128 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7129 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1
C7130 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1
C7131 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1
C7132 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7133 nsp CAP, ELECT(10V/100uF) CCEA1AH101T 1
C7135 nsp CAP, CHIP(1005, 50V/220pF, C0G)_SAMSUNG CCUI1H221JAS 1
C7136 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7141 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7142 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7143 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7144 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7145 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7201 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7202 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7203 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7204 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7205 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7206 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7207 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7208 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7209 nsp CAP, ELECT(50V/100uF) CCEA1HH101T 1
C7210 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7211 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C7212 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7213 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C7216 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7217 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7218 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CCUS1A105KCS 1
C7221 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7222 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7223 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7224 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7225 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C7226 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7227 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C7231 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7234 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7235 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7236 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7237 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7238 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7239 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7240 nsp CAP, CHIP(1608, 50V/15pF, C0G)_SAMSUNG CCUS1H150JAS 1
C7241 nsp CAP, CHIP(1608, 50V/15pF, C0G)_SAMSUNG CCUS1H150JAS 1
C7242 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C7244 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7245 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C7246 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7270 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7271 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7272 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7273 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7274 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7275 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7276 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7277 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7278 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7279 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7280 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C7281 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7285 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7301 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7302 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7303 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
16

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
