Denon AVR-X540BT Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q'ty New Ver
C7468 nsp CAP, ELECT(10V/100uF) CCEA1AH101T 1
C7469 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7470 nsp CAP, ELECT(10V/100uF) CCEA1AH101T 1
C7471 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7473 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7477 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7478 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7479 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7480 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7501 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C7502 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7503 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7505 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7506 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C7509 nsp CAP, CHIP(2012, 16V/10uF, X5R)_SAMSUNG CCUC1C106KCS 1
C7510 nsp CAP, CHIP(2012, 16V/10uF, X5R)_SAMSUNG CCUC1C106KCS 1
C7511 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7512 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7514 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CCUC0J226KCS 1
C7515 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CCUC0J226KCS 1
C7516 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CCUC0J226KCS 1
C7517 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7518 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7523 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7524 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7525 nsp CAP, CHIP(2012, 16V/10uF, X5R)_SAMSUNG CCUC1C106KCS 1
C7526 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7527 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7528 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7529 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7530 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CCUC0J226KCS 1
C7531 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7543 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7544 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CCUS1A105KCS 1
C7545 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7549 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7550 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7553 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7554 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7555 nsp CAP, CHIP(2012, 16V/10uF, X5R)_SAMSUNG CCUC1C106KCS 1
C7556 nsp CAP, CHIP(2012, 16V/10uF, X5R)_SAMSUNG CCUC1C106KCS 1
C7557 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7558 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7560 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CCUC0J226KCS 1
C7561 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CCUC0J226KCS 1
C7562 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CCUC0J226KCS 1
C7563 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7566 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7567 nsp CAP, CHIP(2012, 16V/10uF, X5R)_SAMSUNG CCUC1C106KCS 1
C7568 nsp CAP, CHIP(2012, 16V/10uF, X5R)_SAMSUNG CCUC1C106KCS 1
C7569 nsp CAP, CHIP(2012, 16V/10uF, X5R)_SAMSUNG CCUC1C106KCS 1
C7570 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7571 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7573 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CCUC0J226KCS 1
C7574 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CCUC0J226KCS 1
C7575 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7577 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C7578 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1
C7579 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7580 nsp CAP, CHIP(1608, 16V/0.22uF, X7R)_SAMSUNG CCUS1C224KCS 1
C7581 nsp CAP, ELECT(16V/220uF) CCEA1CH221T 1
C7586 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7587 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7588 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7589 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7590 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7591 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7592 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7593 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7594 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7595 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7596 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7597 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7598 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7599 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7600 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7601 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7602 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7603 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7605 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7607 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C7608 nsp CAP, ELECT(50V/100uF) CCEA1HH101T 1
C7609 nsp CAP, ELECT(50V/100uF) CCEA1HH101T 1
C7610 nsp CAP, CHIP(1005, 50V/100pF, C0G)_SAMSUNG CCUI1H101JAS 1
C7611 nsp CAP, CHIP(1005, 50V/100pF, C0G)_SAMSUNG CCUI1H101JAS 1
C7612 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7613 nsp CAP, CHIP(1005, 50V/100pF, C0G)_SAMSUNG CCUI1H101JAS 1
C7614 nsp CAP, CHIP(1005, 50V/100pF, C0G)_SAMSUNG CCUI1H101JAS 1
C7615 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7617 nsp CAP, CHIP(1608, 50V/2700pF, X7R)_SAMSUNG CCUS1H272KCS 1
C7618 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7619 nsp CAP, CHIP(1608, 50V/220pF, C0G)_SAMSUNG CCUS1H221JAS 1
C7620 nsp CAP, CHIP(1608, 50V/220pF, C0G)_SAMSUNG CCUS1H221JAS 1
C7621 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7622 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7623 nsp CAP, CHIP(1608, 50V/220pF, C0G)_SAMSUNG CCUS1H221JAS 1
C7624 nsp CAP, CHIP(1608, 50V/220pF, C0G)_SAMSUNG CCUS1H221JAS 1
C7627 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C7629 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C7630 nsp CAP , ELECT(63V/100uF) CCEA1JH101E 1
C7631 nsp CAP , ELECT(63V/100uF) CCEA1JH101E 1
C7638 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7639 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C7641 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7642 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C7643 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C7644 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C7645 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C7646 nsp CAP, ELECT(50V/100uF) CCEA1HH101T 1
C7647 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7648 nsp CAP, ELECT(50V/100uF) CCEA1HH101T 1
C7649 nsp CAP, ELECT(50V/100uF) CCEA1HH101T 1
C7650 nsp CAP, ELECT(50V/100uF) CCEA1HH101T 1
C7651 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C7652 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1
C7653 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1
C7654 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1
C7655 nsp CAP, CHIP(1608, 50V/1500pF , X7R)_SAMSUNG CCUS1H152KCS 1
C7656 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
18

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
