14
DHT-390XP
AVR-390
8. PCB ASSY POWER
(1) Disconnect the connector wires and remove the screws.
9. PCB ASSY MAIN
Please refer to "EXPLODED VIEW" for the disassembly method of PCB ASSY MAIN.
Proceeding : CABINET TOP → CHASSIS BACK → PCB ASSY POWER
Top view
CP103
POWER Board
Proceeding : CABINET TOP → CHASSIS BACK → PCB ASSY MAIN
