DHT-390XP
WIRE ARRANGEMENT
If wire bundles are untied or moved to perform adjustment or parts replacement etc., be sure to rearrange them neatly
asthey were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noisegeneration.
Wire arrangement viewed from the top
Back Panel side
Front Panel side
