Audio
Analog Outputs Output Level (balanced XLR): +4 dBu = +1.786 dBV
Output Level
(unbalanced RCA): +6 dBV
Digital Output
Output Level
(coaxial): 0.5V, 75 Ω
Signal Format: AES/EBU
Surround Audio
DTS-Master Audio, DTS-HD High Resolution Audio,
DTS Digital Surround, Dolby TrueHD, Dolby Digital (AC-3),
Dolby Digital Plus (7.1ch)
Frequency Response
20 Hz – 20 kHz (+0.5 dB)
Signal-to-Noise Ratio
> 100 dB
(A-weighted)
Total Harmonic Distortion
< 0.05%
Dynamic Range
> 100 dB
(A-weighted)
Headroom
6 dB
Channel Separation
> 90 dB
Communication
Remote Control
Infrared protocol, > 200 mV transmission output level
Serial Remote Connector: 9-pin D-Sub female, RS-232C
Mode: Full duplex
Baud Rate: 9600 or 38400 bps
(selectable)
Ethernet Connector: LAN port
Standards: Ethernet
(10 Mbps), Fast Ethernet (100 Mbps)
Other / General
Connections
(2) XLR audio outputs
(L/R, balanced)
(2) RCA audio outputs
(L/R, unbalanced)
(8) RCA audio outputs
(7.1 surround sound)
(1) Coaxial digital audio/visual output
(1) HDMI audio/visual output
(1) LAN port
(1) 9-pin D-Sub female RS-232C port
(1) IEC power connection
Power Connection: IEC
Requirement: 100–240 VAC, 50/60 Hz
Consumption: 15 W typical, < 0.5 W standby
Environmental Conditions Operating temperature: 41 – 95 °F (5 – 35 °C)
Operating humidity: 25 – 85%, no condensation
Dimensions
(width x depth x height, with rack ears)
19.00” x 10.75” x 1.73”
483 mm x 273 mm x 44 mm
Weight
(with rack ears)
5.9 lbs.
2.7 kg
