Denon DN-A100 Service Manual

15
DN-A100
D363,364 00D 943 0182 609 DIODE 1SS133 CVD1SS133MT
D561 00D 943 0182 609 DIODE 1SS133 CVD1SS133MT
D603 00D 943 0182 502 DIODE 1N4003 CVD1N4003ST
D604-609 00D 276 0704 903 DIODE 1SR35-400A
D610 00D 943 0196 306 ZENER DIODE ZJ7.5B CVDZJ7.5BT
D611 00D 943 0196 209 ZENER DIODE ZJ4.7B CVDZJ4.7BT
D612 00D 943 0182 609 DIODE 1SS133 CVD1SS133MT
D613,614 - WIRE, COPPER C3A206
D615 00D 943 0182 609 DIODE 1SS133 CVD1SS133MT
D901 00D 943 0195 608 DIODE FMG-22S(A-K-A) CVDFMG-22S
D902 00D 943 0195 501 DIODE FMG-22R(K-A-K) CVDFMG-22R
D903-908 00D 943 0182 502 DIODE 1N4003 CVD1N4003ST
D911,912 00D 943 0182 502 DIODE 1N4003 CVD1N4003ST
D913,914 00D 943 0195 909 ZENER DIODE ZJ16B CVDZJ16BT
D915-917 00D 943 0182 502 DIODE 1N4003 CVD1N4003ST
RESISTORS GROUP
R345-348 - RES, CARBON 3.9k ohm 1/4W J CRD25FJ392T
R349-352 00D 943 0194 201 RES, CEMENT 0.22 ohm 5W K CRF5EKR22H
R369 - RES, CARBON 22 ohm 1/4W J CRD25FJ220T
R370 00D 943 0200 409 RES, METAL OXIDE 390 ohm 1W J CRG1ANJ391H
R371 - RES, CARBON 22 ohm 1/4W J CRD25FJ220T
R372 00D 943 0200 409 RES, METAL OXIDE 390 ohm 1W J CRG1ANJ391H
R373,374 00D 943 0200 506 RES, METAL OXIDE 10 ohm 1W J CRG1ANJ100H
R382 - RES, CARBON 22 ohm 1/4W J CRD25FJ220T
R384 - RES, CARBON 22 ohm 1/4W J CRD25FJ220T
R388-391 - RES, CARBON 3.9k ohm 1/4W J CRD25FJ392T
R902,903 - RES, CARBON 22k ohm 1/4W J CRD25TJ223T
R904,905 00D 943 0194 405 RES, FUSE 0.47 ohm 1W J CRQ1AJR47H
R912 00D 943 0194 308 RES, FUSE 0.3 ohm 1/6W K CRQ16AKR30T
VR31,32 00D 943 0196 908 SEMI FIXED RESISTOR 500 ohm CVN1SA501B01T
CAPACITORS GROUP
C101-104 - CAP, CERAMIC 100pF 50V KB CCKT1H101KB
C105,106 - CAP, ELECT 10uF 50V CCEA1HH100T
C109,110 - CAP, ELECT 220uF 16V CCEA1CH221T
C111,112 - CAP, MYLAR 6800pF 50V J HCQI1H682JZT
C113,114 - CAP, MYLAR 0.018uF 50V J HCQI1H183JZT
C115,116 - CAP, MYLAR 6800pF 50V J HCQI1H682JZT
C117,118 - CAP, ELECT 10uF 50V CCEA1HH100T
C119,120 - CAP, MYLAR 3900pF 50V J HCQI1H392JZT
C121,122 - CAP, ELECT 22uF 50V CCEA1HH220T
C123,124 - CAP, CERAMIC 0.1uF 50V ZF CCFT1H104ZF
C215,216 - CAP, ELECT 10uF 50V CCEA1HH100T
C217 - CAP, CERAMIC 47pF 50V JC CCCT1H470JC
C235,236 - CAP, CERAMIC 0.022uF 50V ZF CCFT1H223ZF
C301,302 - CAP, ELECT 22uF 50V CCEA1HH220T
C303,304 - CAP, CERAMIC 220pF 50V KB CCKT1H221KB
C305,306 - CAP, CERAMIC 1000pF 50V KB HCBS1H102KBT
C309-312 00D 943 0188 700 CAP, ELECT 100uF/25V (RA3) CCEA1ERA3101T
C313,314 - CAP, CERAMIC 5pF 50V CC CCCT1H050CC
C315-318 - CAP, MYLAR 3900pF 50V J HCQI1H392JZT
C319,320 00D 943 0189 204 CAP, ELECT 22uF 50V (RFS) CCEA1HRFS220E
Ref. No. nsp Part No. Part Name Remarks Q'ty New
