21
DN-A100
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Ref. No. nsp Part No. Part Name Remarks Q'ty New
1 nsp 00D 943 0194 309 MAIN PWB ASS'Y COP11904B 1
2 nsp 00D 943 0194 105 FRONT PCB ASS'Y COP11903B 1
2-1 - FRONT PWB
2-2 - INPUT PWB
2-3 - VOLUME PWB
2-4 - JACK PWB
2-5 - POWER PWB
3 nsp 00D 943 0190 206 WINDOW, REMOCON CGU1A396A8 1
4 nsp 00D 943 0189 903 LENS CGL1A254 1
5 nsp 00D 943 0190 002 FUNCTION LENS CGL1A255Z 1
6 nsp 00D 943 0187 109 DIRECT KNOB CBC1A154B2 1
7 00D 943 0187 303 PUSH KNOB CBC1A155B2 3
8 00D 943 0179 502 KNOB, POWER CGK1A124ZA 1
9 nsp 00D 131 0165 003 DENON BADGE PRO(W-A) 1 *
10 nsp 00D 943 0190 303 INNER PANEL CGW1A425B2 1
11 00D 943 0188 001 ROTARY KNOB CBN1A211B2 3
12 00D 943 0187 604 VOLUME KNOB CBN1A209B2 1
13 00D 943 0187 808 INPUT KNOB CBN1A210B2 1
14 - CHASSIS, BOTTOM CUA1A269 1
15-1 nsp 00D 104 0334 007 FOOT 4
15-2 nsp 00D 943 0179 900 CUSHION , FOOT CHG2A289 4
16 nsp 00D 943 0193 902 COVER, SCREW CMD1A495 1
17 nsp 00D 943 0095 107 HOLDER, PCB CHE170 2
18 nsp 00D 943 0191 205 HOLDER, PCB CHE1A030 1
19 nsp 00D 943 0094 700 RUBBER CHG1A113 2
20 - HEAT SINK CMY1A268 1
21 - HEAT SINK BRACKET CMD1A597 1
22 - BRACKET CMD1A596 1
23 00D 943 0192 806 FRONT PANEL CKM1A179XC45 1 *
24 nsp 00D 943 0192 505 REAR PANEL CKF1A317X 1 *
25 nsp 00D 943 0199 303 TERMINAL , GROUND KMA1A006 1
! 26 00D 943 0180 407 CORD, POWER(EUR) CJA2B043ZA 1
27 nsp 00D 943 0095 505 BUSHING, AC CORD KHR1A028 1
! 28 00D 943 0193 407 TRANSFORMER, POWER CLT5R037ZE 1
29 nsp 00D 943 0192 408 TOP CABINET CKC1A176S56 1
★ 30
00D 943 0193 708 FERRITE CORE(21.2X6.4X12.7) CLZ9Z028Z 1
★ 31
nsp 00D 943 0186 401 HEMELON TAPE CHS1A032 3
★ 32
00D 943 0164 203 FERRITE, RING CLZ9W003Z 1
★ 33
nsp 00D 943 0191 302 CLAMPER CHR301 8
★ 34
- LOCKER CRE1A037 8
★ 35
nsp 00D 129 0256 003 CLOTH TAPE (W20) L=30 1
★ 36
nsp 00D 129 0256 016 CLOTH TAPE (W10) L=230 1
★ 37
nsp 00D 125 0092 029 BUTYL TAPE (W=15) L=65 2
★ 38
nsp 00D 125 0096 025 NITOFLON TAPE (W15) L=65 2
★ 39
nsp 00D 125 0092 016 BUTYL TAPE (W=25) L=170 1
★ 40
nsp 00D 125 0096 012 NITOFLON TAPE (W25) L=170 1
★ 41
nsp 00D 125 0097 011 BUTYL TAPE (W25 T2) L=100 1
★ 42
nsp 00D 125 0096 012 NITOFLON TAPE (W25) L=100 1
To Next Page
