Denon DN-A100 Service Manual

19
DN-A100
C704 - CAP, ELECT 220uF 16V CCEA1CH221T
C705 - CAP, CERAMIC 0.01uF 50V ZF CCFT1H103ZF
C706 - CAP, CERAMIC 47pF 50V JC CCCT1H470JC
! C901,902 00D 943 0024 408 CAP, CERAMIC 0.0047uF/2.5KV KCKDKS472ME
C903 - CAP, CERAMIC 0.1uF 50V ZF CCFT1H104ZF
C904 00D 943 0188 603 CAP, ELECT 1000uF 25V CCEA1EH102E
C905 - CAP, ELECT 0.47uF 50V CCEA1HHR47T
C906 - CAP, CERAMIC 0.01uF 50V ZF CCFT1H103ZF
OTHERS PARTS GROUP
BK91 - BRACKET, PCB(A) CMD1A188
BN50 - WIRE ASS'Y 2.0MM/130MM/8P CWB2B908130EN
BN51 - WIRE ASS'Y 2.0MM/220MM/4P
CWZPMA500AEBN51
BN52 - WIRE ASS'Y 2.5MM/80MM/4P
CWZPMA500AEBN52
BN53 - WIRE ASS'Y 2.0MM/270MM/7P CWB2B907270EN
BN54 - WIRE ASS'Y CWB1C904220BM
BN56,57 - WAFER CJP07GF107ZY
BN58 - WIRE ASS'Y CWB2B910100EN
BN59 - WIRE ASS'Y CWB2B903080EN
CN56,57 - WAFER CJP07HA37ZM
CN59 - WAFER, STRAIGHT, 3PIN CJP03GA19ZY
CN90 - WAFER CJP02KA060ZY
CN91 - WAFER CJP02GA89ZY
CN92 - WAFER, STRAIGHT, 6PIN CJP06GA19ZY
CN94 - WAFER CJP02GA89ZY
! F901 00D 943 0199 109 FUSE 2.5A/250V KBA2C2500TLEY
! F902 00D 943 0199 109 FUSE 2.5A/250V KBA2C2500TLEY
JK61 00D 943 0198 003 JACK, PHONE HJJ2E018Z
JW54 - WIRE ASS'Y(1P) CWE8202080RV
JW62 - WIRE ASS'Y CWE8202110RV
JW91 - WIRE ASS'Y (RED/N.C/BLACK) CWB4FA32300PU
! OL91 00D 943 0199 206 OUTLET, AC(EUR/1P) KJJ7A022Z
RC71 00D 943 0194 706 SENSOR, REMOTE (KSM603TH2E) CRVKSM603TH2E
RY91 00D 943 0200 807 RELAY, G2R-14 (DC 5V) CSL2C002ZE
RY92 00D 943 0194 900 RELAY, G5PA-1 (DC 6V) CSL1E002ZE
SW51 00D 943 0194 803 SW, PUSH (JPS-4281SA) CSH2D013Z
SW52-54 00D 943 0199 400 SW, PUSH (220014) KSH2B003Z
SW91 00D 943 0140 609 SW, PUSH (CSH1A010ZV) CSH1A010ZV
! TRS1 00D 943 0193 203 TRANSFORMER, SUB CLT5I008ZE
- HOLDER, FUSE for F901,902 KJCFC5S
Ref. No. nsp Part No. Part Name Remarks Q'ty New
