9
DN-A100
4. DIODES (LED included)
5. POSISTOR
PTFM04BB222QN34 (TH51)
1SS133M
1N4003
SML1216W (Red/Green)
ZJ4.7B
ZJ7.5B
ZJ15B
ZJ16B
FMG-22S
FRONT
VIEW
A
K
A
FMG-22R
FRONT
VIEW
AKK
SEL-2915A (Orange)
TOP VIEW TOP VIEW
RED ANODE
CATHODE
GREEN ANODE
