Denon DN-C615 - Main Unit and Chassis Parts List

33
33
DN-C615
PARTS LIST OF EXPLODED VIEW
Ref. No. Part No. Part Name Remarks Q'ty NEW
1 GU-3502 MAIN UNIT
1-1 MAIN UNIT
1-2 DISPLAY SW UNIT
1-3 TRANS UNIT
1-4 POWER SW UNIT
1-5 H/P UNIT
2 411 0962 856 CHASSIS 1 *
3 412 5001 003 TRANS BRACKET 1
4 105 1419 005 BACK PANEL For E3 1 *
4 105 1419 018 BACK PANEL For E2,E2K 1 *
! 5 233 6440 002 POWER TRANS 1
6 443 0518 003 P.C.B.HOLDER 1
7 412 2814 057 CARD SPACER (L=12) 3
8 411 2025 005 MECHA BASE 1 *
9 461 1143 006 FFC COVER 1
10 479 0003 025 PUSH RIVET 2
11 337 0100 006 CD MECHA(CD11FTA3N) 1
12 144 2411 117 FRONT PANEL 1 *
13 146 1392 673 SUB PANEL ASS'Y 1 *
14 113 1541 000 FUNCTION KNOB 1
15 113 1561 006 MANUAL SEARCH KNOB 1
16 113 9245 201 TENKEY 1
17 113 1540 108 SERIES KNOB 1
18 412 4998 007 SW BRACKET 1
19 461 1134 002 EMI GASKET UC-3E0690 40
20 445 8028 009 CORD HOLDER 1
21 461 0706 114 FOOT SHEET 2
22 461 0740 002 SHEET 2
23 113 1895 002 POWER KNOB 1
24 146 2297 007 LOADER PANEL 1 *
25 445 8028 009 CORD HOLDER 1
26 206 2155 001 AC CORD W/CON.E3 For E3 1
26 206 2089 106 AC CORD W/CON.E2 For E2 1
26 206 2178 004 KOREA AC CORD VH For E2K 1
27 445 0084 009 CORD BUSH For E3 1
27 445 0056 008 CORD BUSH For E2,E2K 1
28 393 8067 002 FL TUBE(BJ899GN) 1 *
29 009 0235 063 23P FFC (1.0) 1 *
 30 009 0241 002 16P FFC CABLE 1 *
31 204 0307 091 6P KR-KR CON.CORD 1
32 203 8305 034 5P KR-KR CON.CORD 1
33 203 5307 022 3P VH-VH CON.CORD 1 *
34 102 0425 237 TOP COVER 1
35 412 4999 006 MOUNT BRACKET 2 *
36 206 1087 057 FUSE (ET0.4A) For E3 1 *
36 206 1087 060 FUSE (ET0.2A) For E2,E2K 1 *
 37 513 3736 039 FUSE LABEL (0.2A) 1
38 449 0201 004 P.W.B. HOLDER 1
 39 513 3826 004 E2 LASER CAUTION For E2 1
 40 513 3745 004 EMI LABEL (KOREA) For E2K 1
 41 513 2303 007 VERSION LABEL 1
 42 513 1519 009 MANUFAC.DATE LABEL For E3 1
 43 513 3809 047 RATING SHEET For E3 1 *
Note: The symbols in the column “Remarks” indicate the following destinations.
E3:U.S.A. & Canada model E2: Europe model
E2K:Korea model
