For system connections, also see the section “System connection
with the DENON DRA-F109 receiver” (vpage7).
NOTE
•Do not plug in the power cord until all connections have been
completed.
•When making connections, also refer to the owner’s manual of the
other components.
•Be sure to connect the left and right channels properly (left with left,
right with right).
•Do not bundle power supply cords together with connection cables.
Doing so can result in humming or noise.
Cables used for connections
Select the cables according to the equipment being connected.
Audio cable (supplied)
Coaxial digital cable
System cable
Audio cable (sold separately)
Audio cable
R
L
R
L
Connections
Connecting the amplifier
Analog connections
R
L
R
L
AUDIO
AUDIO
RL
IN
Amplifier
Digital connections
Connect digital devices such as AV receivers and D/A converters
with the unit to enjoy digital audio output from the unit.
AUDIO
DIGITAL
IN
AV receivers /
D/A converters
