DRA-700AE/700AEDAB/500AE

FRONT P.W.B. UNIT ASSY

Ref. No. nsp Part No. Part Name Remarks Q'ty New

SEMICONDUCTORS GROUP

IC301 00D 960 0180 004 IC LC75721E

for 500AE J127757210010S

IC401 00D 963 0354 606 IC CPU MICRO PROCESS(D031)

for 700AE, 700AEDAB

M3062LFGPFP

8952700000010

IC401 00D 963 0354 703 IC CPU MICRO PROCESS(L009)

for 500AE

M3062LFGPFP

8952500000010

IC402 00D 963 0057 602 IC TDA7330BD

J080733000010S

IC403 00D 960 0100 301 IC KIA7812API

J126781200040S

IC404 00D 963 0267 007 IC M24C64

for 700AE, 700AEDAB J000240640010S

IC404 00D 963 0313 605 IC 24LC16B

for 500AE J000241600050S

Q301 00D 963 0121 402 TR KRA104S

for 700AE, 700AEDAB J520010400210S

Q303 00D 960 0005 202 TR KTC3198Y

for 700AE, 700AEDAB J5023198Y0000S

Q303 00D 963 0121 606 TR KRC107S (NH)

for 500AE J522107S00210S

Q304 00D 963 0121 402 TR KRA104S

for 500AE J520010400210S

Q305,306 00D 963 0120 704 TR KRA102S(PB)

for 500AE J520010200210S

Q307 00D 963 0120 801 TR 2SC KRC102S (NB)

for 500AE J522010200210S

Q308-310 00D 963 0120 704 TR KRA102S(PB)

for 500AE J520010200210S

Q311,312 00D 963 0120 801 TR 2SC KRC102S (NB)

for 500AE J522010200210S

Q317 00D 963 0121 606 TR KRC107S (NH)

for 500AE J522107S00210S

Q318 00D 963 0120 704 TR KRA102S(PB)

for 500AE J520010200210S

Q319,320 00D 963 0121 606 TR KRC107S (NH)

for 500AE J522107S00210S

Q321 00D 963 0120 704 TR KRA102S(PB)

for 500AE J520010200210S

Q334 00D 963 0120 704 TR KRA102S(PB)

for 700AE, 700AEDAB J520010200210S

Q335 00D 963 0121 606 TR KRC107S (NH)

for 700AE, 700AEDAB J522107S00210S

Q336 00D 963 0120 704 TR KRA102S(PB)

for 700AE, 700AEDAB J520010200210S

Q337 00D 963 0121 606 TR KRC107S (NH)

for 700AE, 700AEDAB J522107S00210S

Q401 00D 963 0120 704 TR KRA102S(PB)

J520010200210S

Q404 00D 963 0121 509 TR KTC3875S

J522038750210S

Q405 00D 960 0285 006 TR KRC104S (ND)

J522104S00210S

Q407 00D 963 0245 003 TR 2SC KRC106S (NF)

J522010600210S

Q408,409 00D 963 0044 301 TR KTC2875B(MB)

J5222875B0010S

Q410 00D 963 0245 003 TR 2SC KRC106S (NF)

J522010600210S

Q411 00D 963 0102 803 TR 2SA933S

J5000933S0050S

Q412,413 00D 963 0044 301 TR KTC2875B(MB)

J5222875B0010S

Q414 00D 963 0120 704 TR KRA102S(PB)

J520010200210S

Q415,416 00D 963 0120 704 TR KRA102S(PB)

for 700AE, 700AEDAB J520010200210S

Q417 00D 963 0120 704 TR KRA102S(PB)

J520010200210S

Q418 00D 963 0121 509 TR KTC3875S

J522038750210S

Q419 00D 963 0102 803 TR 2SA933S

J5000933S0050S

Q607-610 00D 963 0044 301 TR KTC2875B(MB)

for 700AE, 700AEDAB J5222875B0010S

Q613-616 00D 963 0044 301 TR KTC2875B(MB)

for 700AE, 700AEDAB J5222875B0010S

D301 00D 963 0020 309 D,SWITCHING 1SS133T

K000013300520S

D301H 00D 963 0219 709 D,SWITCHING 1N4148W

K005041480020S

D302 00D 963 0020 309 D,SWITCHING 1SS133T

K000013300520S

D302H 00D 963 0219 709 D,SWITCHING 1N4148W

K005041480020S

D303 00D 963 0020 309 D,SWITCHING 1SS133T

K000013300520S

D303H 00D 963 0219 709 D,SWITCHING 1N4148W

K005041480020S

D304 00D 963 0020 309 D,SWITCHING 1SS133T

K000013300520S

D304H 00D 963 0219 709 D,SWITCHING 1N4148W

K005041480020S

D305-307 00D 963 0020 309 D,SWITCHING 1SS133T

for 700AE, 700AEDAB K000013300520S

D305-307 00D 963 0219 709 D,SWITCHING 1N4148W

for 500AE K005041480020S

D308 00D 963 0020 309 D,SWITCHING 1SS133T

for 700AE, 700AEDAB K000013300520S

D310 00D 963 0020 309 D,SWITCHING 1SS133T

for 500AE K000013300520S

D404 00D 963 0020 309 D,SWITCHING 1SS133T

K000013300520S

D405 00D 963 0219 709 D,SWITCHING 1N4148W

K005041480020S
