Display
A
Input mode indicators
These light according to the audio input mode settings of each input
source. (v p. 140)
B
Tuner reception mode indicators
These light up according to the reception conditions when the input
source is set to “Tuner”.
TUNED: Lights up when the broadcast is properly tuned in.
STEREO: Lights up when receiving FM stereo broadcasts.
C
Sleep timer indicator
This lights when the sleep mode is selected. (v p. 103)
D
Volume indicator
E
MUTE indicator
This blinks while the sound is muted. (v p. 52)
F
Information display
The input source name, sound mode, setting values and other
information are displayed here.
G
Input signal indicators
The respective indicator will light corresponding to the input signal.
(v p. 140)
H
ZONE2 indicator
This lights up when ZONE2 (another room) power is turned on.
(v p. 116)
