Electrical Characteristics
4 Electrical Characteristics
Note: All voltages are measured with respect to ground (Pin 8). The voltage levels are valid if other ratings are
not violated.
4.1 Absolute Maximum Ratings
Note: Absolute maximum ratings are defined as ratings, which when being exceeded may lead to destruction
of the integrated circuit. For the same reason make sure, that any capacitor that will be connected to pin 7
(VCC) is discharged before assembling the application circuit.
4.2 Operating Range
Note: Within the operating range the IC operates as described in the functional description.
Parameter Symbol Limit Values Unit Remarks
min. max.
HV Voltage V
HV
-500V
VCC Supply Voltage V
VCC
-0.3 27 V
REG Voltage V
REG
-0.3 5.0 V
ZC Voltage V
ZC
-0.3 5.0 V
CS Voltage V
CS
-0.3 5.0 V
OUT Voltage V
OUT
-0.3 27 V
Junction Temperature T
j
-40 125 qC
Storage Temperature T
S
-55 150 qC
Thermal Resistance
Junction-Ambient
R
thJA
- 90 K/W PG-DIP-8
ESD Capability V
ESD
- 2 kV Human body model
1)
1)
According to EIA/JESD22-A114-B (discharging a 100pF capacitor through a 1.5k: series resistor)
Parameter Symbol Limit Values Unit Remarks
min. max.
VCC Supply Voltage V
VCC
V
VCCUVP
V
VCCOVP
V
Junction Temperature T
jCon
-25 125 °C
