18
Before use Connections
Basic
operations
Installing and setting up
supplied software
USB settings
Troubleshooting Index
Specifications
Signal system chart
Part names and
functions
Top panel
Q3 Q4 Q6 Q9Q8Q5
W8
W7
W6
W4
W1
W3
W2
W5
W0
Q7
q
w
e
y
i
o
Q2
Q0
Q1
u
t
r
Q4 Cue button (CUE) ······································· (11)
Sets the cue point and stutters the cue point
when pushed repeatedly.
Q5 Play/pause button (13)
Plays back when pressed while playback is
stopped. Pauses playback when pressed during
playback.
Q6 VINYL switching button (VINYL MODE)
ON:SwitchestoVINYLmode.
•The touch sensor is enabled when in VINYL
mode.
OFF: Switches to BEND mode.
•The touch sensor is disabled when in BEND
mode.
Q7 Pitch bend adjustment buttons
(PITCH BEND –/+)
Adjust the pitch temporarily.
•Hold down W7 SHIFT and press this button to
fastforward/rewind.
Q8 Channel fader knob
Adjusts the mixing level for each deck.
Q9 Crossfader knob
Adjusts the output balance of the channel level.
W0 Channel input level adjustment knob
(LEVEL)
W1 Load button (LOAD A, LOAD B)
Loads the file selected using W3 SEL. to either
DECK A or DECK B.
•Press this button twice quickly to load the
same file as one on the other deck.
W2 Channel isolator EQ adjustment knob
(HI/MID/LOW)
Adjusts the input signal frequency response for
each channel.
•TurntothelefttocutthesoundattheHI/MID/
LOW frequency band (isolator function).
W3 Track selection knob (SEL.)
Turn the knob to scroll through the browser list,
and press the knob to select a file.
Turn the track selection knob:
Scrolls through the browser list.
Press the track selection knob:
Switch the focus of browser.
To Next Page
