Denon RCD-M41 User Manual

o
Desired sound does not come out
Symptom Cause / Solution Page
Left/right volume balance is
unbalanced.
0
Press the SDB/TONE button on the remote control to adjust the balance. 42
No sound from the sub
woofer.
0
Check the subwoofer connections. 19
0
Switch the subwoofer power on. －
Set values are not reflected
in “SDB (Super Dynamic
Bass)”, “BASS” and
“TREBLE”.
0
“SDB (Super Dynamic Bass)”, “BASS” and “TREBLE” setting values are not reflected in subwoofer out. 42
0
Set “OFF” to the “S.DIRECT”. 42
Headphone volume is low.
0
Switch “H/P AMP GAIN” to “MIDDLE” or “HIGH” if using headphones with high impedance or low
sensitivity.
49
o
Audio from digital devices cannot be played back (Optical)
Symptom Cause / Solution Page
“SIGNAL UNLOCK” is
displayed.
0
When digital audio signals cannot be detected properly, “SIGNAL UNLOCK” is displayed. 39
0
“SIGNAL UNLOCK” is displayed when audio signals that are not supported by this unit are input. Check
the audio output signal format from your digital device.
39
Contents Connections Playback Settings Tips Appendix
57
Front panel Display Rear panel Remote Index

Denon RCD-M41 Specifications

General

Radio type	Portable
Tuner type	Digital
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Radio Data System (RDS)	Yes
Display type	LED
Thermometer	-
Product color	Silver
Volume control	Rotary
Power source	AC
Input frequency	50 / 60 Hz
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	70 W
USB port	No
RMS rated power	- W
Type	Home audio mini system
Audio formats supported	MP3
Impedance	6 Ω
Speaker type	2-way
Frequency range	45 - 40000 Hz
Woofer diameter	120 mm
Tweeter diameter	25 mm

Weight and Dimensions

Depth	309 mm
Width	210 mm
Height	115 mm
Weight	4000 g
