137
S-301
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model JP : Japan model
Ref. No. nsp Part No. Part Name Remarks Q'ty New
1 00D 1U-3694A MAIN UNIT(E3) for E3 1 *
1 00D 1U-3694B MAIN UNIT(E2) for E2 1 *
1 00D 1U-3694C MAIN UNIT(JP) for JP 1 *
2 00D 1U-3695A I/F UNIT(E3) for E3 1 *
2 00D 1U-3695B I/F UNIT(E2) for E2 1 *
2 00D 1U-3695C I/F UNIT(JP) for JP 1 *
2-1 - LOCAL POWER UNIT
2-2 - I/F UNIT
2-3 - CONVERT UNIT
3 nsp 00D 1U-3681A DISPLAY UNIT 1 *
3-1 - DISPLAY UNIT
3-2 - DISPLAY RIGHT UNIT
3-3 - DISPLAY LEFT1 UNIT
3-4 - DISPLAY LEFT2 UNIT
3-5 - 1U-3681-5
3-7 - 1U-3681-7
3-10 - 1U-3681-10
3-12 - 1U-3681-12
4 00D 1U-3692A DVD UNIT(E3) for E3 1 *
4 00D 1U-3692B DVD UNIT(E2) for E2 1 *
4 00D 1U-3692C DVD UNIT(JP) for JP 1 *
5 00D 1U-3693A USB UNIT ASS'Y 1 *
5-1 00D 1U-3693A-1 USB UNIT *
5-2 00D 1U-3693A-2 USB I/F UNIT *
6 nsp 00D 411 2085 100 MAIN CHASSIS 1 *
7 nsp 00D 105 1646 409 REAR PANEL for E3 1 *
7 nsp 00D 105 1646 412 REAR PANEL for E2 1 *
7 nsp 00D 105 1646 425 REAR PANEL for JP 1 *
8 00D 421 0839 009 FAN F410T-12L1C 1 *
9 nsp 00D 412 5274 005 FAN GUARD G40-2 1 *
10 nsp 00D 412 5236 108 MECHA BRACKET 1 *
11 nsp 00D 412 5268 008 SPACER SUPPORT 1 *
16 nsp FGTD5HPE3 DVD MECHA MODULE for E3 1 *
16 nsp FGTD5HPE2 DVD MECHA MODULE for E2 *
16 nsp FGTD5HPJPN DVD MECHA MODULE for JP *
16-1 00D 337 0133 109 DVD MECHA(TD-5HP-D8-DE) 1
17 nsp 00D 461 1240 019 SPACER 2
18 nsp 00D 412 5284 008 EARTH PLATE 1 *
19 00D 216 0129 007 AM FM TUNER(E3 RDBS) for E3 1
19 00D 216 0125 001 AM FM TUNER(E2) for E2 1
19 00D 216 0127 009 AM FM TUNER(J) for JP 1
20 00D 144 2943 300 FRONT PANEL L 1 *
21 00D 144 2944 309 FRONT PANEL R 1 *
