PARTS LIST OF DVD MECHANISM UNIT
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
00D 337 0133 109 DVD MECHA (TD-5HP-DE)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
1 00D 9KC 1A01 7 MAIN CHASSIS ASS'Y 1
2 00D 9KA 7P08 5 CLAMPER BRACKET 1
3 00D 9KC 4P00 7F GUIDE CLAMP BRACKET 1
4 00D 9KC 2A00 3 LOADING MOTOR ASS'Y 1
5 00D 9KC 2G02 9 LOADING GEAR 1
6 00D 9KB 9G03 0 LOADING GEAR 2ND 1
7 00D 9KB 9G03 1 LOADING GEAR 3RD 1
8 00D 9KA 2G41 7 SUB CHASSIS-L 1
9 00D 9KA 2G41 8 SUB CHASSIS-R 1
10 00D 9KA 2G39 9C TRAY 1
11 00D 9KC 1G00 3 SLIDE-CAM 1
12 00D 9KC 1G00 4 TRAVERSE ARM 1
14 00D 9KA 7G20 2 CLAMPER H 1
15 00D 9KA 7G20 3 CLAMPER L 1
16 00D 9KB 9G01 5 LOADING BELT 1
17 00D 9KC 1P01 4 SWITCH P.W.B. 1
18 00D 9KC 2G04 3 5P PH WIRE 1
19 00D 9KS 01W2 04 SWITCH ESE22MH21 1
20 00D 9KS 01W2 05 SWITCH ESE22MH23 1
21 00D 9KP 26C6 25 POLY.SLIT WASHER 2.6X6X0.25C 3
22 00D 445 8004 007 WIRE CLAMPER 1
23 00D 9KS 17N0 22 PRECISION SCREW 1.7X2.2 TYPE3 2
24 00D 9KB 26BK 06 SCREW 2.6X6 CBTS(B)-Z 6
25 00D 9KS 20TK 33 PRECISION SCREW 2X3(S) TYPE3 1
26 00D 9KB 20PK 06 SCREW 2X6 CBTS(P)-Z 2
27A 00D 9KC 2A06 3B TRAVERSE MECHA (FEED) ASS'Y Assembled part 1
23 - PRECISION SCREW 1.7X2.2 TYPE3 3
27 - PU CHASSIS ASS'Y 1
28 - SHAFT HOLDER L 1
29 - SHAFT HOLDER R 1
30 - SHAFT TILT BASE 1
31 - SHAFT TILT PLATE 1
32 - TILT SPRING 2
33 - MAIN SHAFT 1
34 - SUB SHAFT 1
35 - PU RACK GEAR 1
37 - PICK UP HOP-1200R 1
38 - PU SPRING 1
39 - SHAFT SPRING 1
40 - RACK GEAR SPRING 1
42 - T/T MOTOR ASS'Y 1
43 - SCREW 2.6X6 CBTS(S)-Z 2
44 - SCREW 2.6X4 CBTS(S)-Z 1
46 - SCREW 2.6X15 CFTS(S)-Z 2
47 - SCREW 3X4 BSS 2
48 - SCREW 3X8 BSS (A) 1
63 - PRECISION SCREW 1.7X5 TYPE3 1
23 - PRECISION SCREW 1.7X2.2 TYPE3 2
36 - FEED GEAR 2ND ASS'Y 1
