148
S-301
SC-S301 PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model JP : Japan model
Ref. No. nsp Part No. Part Name Remarks Q'ty New
9L nsp 00D 949 0057 509 CABINET(L) for L ch 1
9 CABINET 52-000-190-01 2
1 - PACKING A 29-000-345-01 2 *
2 - PACKING B 29-000-346-01 2
3 - PACKING C 29-000-347-01 2
4 - PACKING D 29-000-348-01 1
5 - PACKING E 29-000-349-01 1
7L - SPEAKER JACK L 45-000-145-01 2
11 - SOUND ABSORBENT 54-000-152-21 3
19 - INSERT NUT 71-099-500-01 *
9R nsp 00D 949 0057 606 CABINET(R) for R ch 1
9 CABINET 52-000-190-01 2
1 - PACKING A 29-000-345-01 2 *
2 - PACKING B 29-000-346-01 2
3 - PACKING C 29-000-347-01 2
4 - PACKING D 29-000-348-01 1
5 - PACKING E 29-000-349-01 1
7R - SPEAKER JACK R 45-000-145-11 2
11 - SOUND ABSORBENT 54-000-152-21 3
19 - INSERT NUT 71-099-500-01 *
10L nsp 00D 949 0057 800 BAFFLE (L) for L ch 1
10 BAFFLE (L) 53-000-222-01 1
8 - PANEL 68-000-078-01 1
12 - NET 55-000-335-01 4
26 - PACKING G 29-000-352-01 4
27 - PACKING H 29-000-352-11 3
28 - PACKING I 29-000-352-21 3
29 - PACKING J 29-000-352-31
10R nsp 00D 949 0057 907 BAFFLE(R) for R ch 1
10 BAFFLE(R) 53-000-222-11 1
8 - PANEL 68-000-078-01 1
12 - NET 55-000-335-01 4
26 - PACKING G 29-000-352-01 4
27 - PACKING H 29-000-352-11 3
28 - PACKING I 29-000-352-21 3
29 - PACKING J 29-000-352-31
1
14 00D 949 0058 605 HOLDER 64-000-274-01 1
13L 00D 949 0058 304 RATING LABEL (L) for L ch 60-002-211-01 1
13R 00D 949 0058 401 RATING LABEL (R) for R ch 60-002-211-11
1
15 nsp 00D 949 0058 809 NETWORK ASSY 67-000-191-01 1
6 - PACKING F 29-000-350-01 *
8
16 nsp 00D 949 0059 507 +P 4X16 TAP TYTE SCREW 70-078-416-06 9
