22
S-301
HRD#
150
O Host read (active-low).
DCI_ACK# O DVD channel data valid (active-low).
AUX4[6] I/O Aux4 data I/O.
HIOCS16#
151
I Device 16-bit data transfer (active-low).
CAMCLK I Camera port pixel clock input.
AUX3[4] I/O Aux3 data I/O.
HCS1FX#
152
O Host select 1 (active-low).
AUX3[7] I/O Aux3 data I/O.
HCS3FX#
153
O Host select 3 (active-low).
AUX3[6] I/O Aux3 data I/O.
HA[2:0]
154, 155, 158
I/O Host address bus.
AUX4[4:2] I/O Aux4 data I/Os.
AUX[0]
160
I/O Auxiliary port 0 (open collector).
I2CDATA I/O I
2
C data I/O.
AUX[1]
161
I/O Auxiliary port 1 (open collector).
I2C_CLK I/O I
2
C clock I/O.
AUX[2]
162
I/O Auxiliary port.
IOW# O I/O write strobe (LCS1) (active-low).
AUX[3]
165
I/O Auxiliary port.
IOR# O I/O read strobe (LCS1) (active-low).
AUX[6:4] 166:168 I/O Auxiliary ports.
AUX[7] 169 I/O Auxiliary port.
LOE# 170 O RISC port output enable (active-low).
LCS[3:0]# 173:176 O RISC port chip select (active-low).
LD[15:0]
178:182,
185:191,194:197
I/O RISC port data bus.
LWRLL# 198 O RISC port low-byte write enable (active-low).
LWRHL# 199 O RISC port high-byte write enable (active-low).
CAMIN0 202 I Camera YUV 0.
CAMIN1 203 I Camera YUV 1.
Name Pin Numbers I/O Definition
