83
S-52/S-52DAB/S-32
4-4 - WINDOW for S-52JP 1 *
4-4 - WINDOW for S-32E2 1 *
4-4 - WINDOW for S-32E3 1 *
4-5 - METAL NET (L) 1 *
4-6 - MATAL NET (R) 1 *
4-7 - BLIND SHEET 1 *
4-8 - SUPPORT SHEET 1 *
4-9 - DOCK LID ASSY 1 *
4-10 - DOC LID COVER 1 *
4-11 - DOCK ESC 1 *
4-12 - ADAPTER SPRING 1 *
5 00D 463 0978 100 SPRING PLATE 2 *
6 00D 113 2109 302 KNOB(2P) A ASSY 1 *
6-1 - KNOB(2P) A BASE 1 *
6-2 - LED LENS 1 *
7 00D 113 2108 303 KNOB(2P) B ASSY 1 *
7-1 - KNOB(2P) B BASE 1 *
7-2 - LED LENS 1 *
8 00D 113 2104 103 KNOB (ON/STBY) 1 *
9 00D 113 2105 005 KNOB (EJECT) for S-52 1 *
9 00D 113 2105 018 KNOB (EJECT) for S-32 1 *
10 00D 113 2106 208 KNOB(PLAY) 1 *
11 00D 113 2111 109 KNOB (3P) 1 *
12 00D 113 2112 302 KNOB (SNOOZE) 1 *
13 00D 443 1625 209 ROTARY KNOB GUIDE 1 *
14 00D 113 2126 000 KNOB (ALARM) 1 *
15 00D 113 2126 013 KNOB (ALARM) 1 *
16 00D 393 6029 107 LCD(MDG24EC18-FJ) 1 *
17 nsp SHIELD PLATE 1 *
18 nsp EARTH PLATE 3 *
19 00D 105 1695 201 REAR PANEL for S-52E3 1 *
19 00D 105 1695 214 REAR PANEL for S-52E2 1 *
19 00D 105 1695 227 REAR PANEL for S-52DABEK 1 *
19 00D 105 1695 243 REAR PANEL for S-32E2 1 *
19 00D 105 1695 256 REAR PANEL for S-32E3 1 *
19 00D 105 1695 269 REAR PANEL for S-52JP 1 *
20 nsp TRANS BRACKET 1 *
! 21 00D 233 6611 006 POWER TRANS(MAIN/E2) for S-52E2/DABEK,S-32E2 1 *
! 21 00D 233 6612 005 POWER TRANS(MAIN/E3) for S-52E3,S-32E3 1 *
! 21 00D 233 0746 003 POWER TRANS(MAIN/J) for S-52JP 1 *
22 nsp UL TUBE (12.7) BK 1 *
23 nsp TRANS SHIELD 1 *
24 nsp TRANS COVER 1 *
25 00D 342 0043 000 FERRITE CLAMP102010N 1
26 00D 216 0134 005 HD TUNER(E3) for S-52E3 1 *
27 00D 216 0125 001 AM FM TUNER(E2) for S-52E2/DABEK,S-32E2 1
27 00D 216 0127 009 AM FM TUNER(J) for S-52JP 1
27 00D 216 0129 007 AM FM TUNER(E3 RDBS) for S-32E3 1
28 nsp ANNTENA CABLE 1
29 nsp HEAT SINK BRACKET 1 *
30 nsp SIDE BRACKET (R) 1 *
31 nsp SIDE BRACKET (L) 1 *
32 nsp EARTH PLATE (REAR) 1 *
33 00D 399 1099 004 WLAN MODULE(11CH) for S-52E3,S-32E3 1
33 00D 399 1100 003 WLAN MODULE(13CH) 1
34 nsp FFC ID SUB ASSY for S-52E3,S-32E3 1
Ref. No. Part No. Part Name Remarks Q'ty New
