84
S-52/S-52DAB/S-32
35 nsp TOP BRACKET 1 *
36 nsp PWB BRACKET 1 *
37 nsp PROTECTION SHEET 1 *
38 nsp PUSH RIVET 2
39 nsp CORD HOLDER 2
40 FGDVS202MS CD MECHA UNIT for S-52 1 *
41 nsp MAIN CHASSIS for S-32 1 *
42 nsp E2 LASER CAUTION for S-52E2/DABEK 1
42 nsp LABEL(A) for S-52E3 1
43 nsp BOTTOM COVER 1 *
44 00D 461 1066 002 FELT 4
45 nsp DRONE CONE COVER 2 *
46 00D 305 0051 103 PR-06 PASSIVE RADIATOR 2 *
47 nsp SP BOX (L) 1 *
48 00D 301 0180 001 77RG15 SPAEKER ASSY 2 *
49 nsp SP BOX (R) 1 *
50 nsp CORD HOLDER 1
51 nsp COVER PLATE 1 *
52 00D 112 1012 109 ROTARY KNOB 1 *
53 854 241 0001 00D KNOB RING SUB ASSY 1 *
54 nsp RATING SHEET for S-52E2 1 *
54 nsp RATING SHEET for S-52E3 1 *
54 nsp RATING SHEET for S-52DABEK 1 *
★ 55A
nsp NO. SHEET for S-52E2/DABEK 1
★ 55A
nsp NO. SHEET for S-32E2 1
★ 55B
nsp NO. SHEET for S-52JP
★ 56
nsp SERIAL NO. SHEET for S-52E3,S-32E3 1
★ 57
nsp DANGEROUS LABEL for S-52E3,S-32E3 1
★ 58
nsp DATE LABEL for S-52E3 1
★ 59
nsp MANUFAC.(J)SUB ASSY for S-52JP 1
★ 60
nsp WIRE CLAMPER 8
61 nsp EMIGASKET RFSG020210 10mm 5
62 00D 216 0135 004 DAB TUNER(VENCE4.2) for S-52DABEK 1
63 nsp DAB PWB BRACKET for S-52DABEK 1
64 nsp SHIELD CASE (DAB) for S-52DABEK 1
65 nsp PWB HOLDER for S-52DABEK 2
70 nsp SP NET CUSHION 10 *
71 00D 461 1307 004 LID CUSHION 2 *
72 00D 461 1305 006 ESC CUSHION 3 *
73 nsp SNOOZE PWB SPACER 3 *
74 00D 461 1306 005 KNOB SPACER 13 *
75 432 510 0010 08D LCD CUSHION 1 *
76 00D 461 1322 005 EMI FILTER CUSHION 1 *
77 00D 461 1324 003 POWER UNIT PWB SHEET 2 *
78 00D 415 1018 002 INSULATING SHEET 3 *
79 00D 461 1314 000 WIRE CUSHION 3 *
80 00D 461 1323 004 MECHA FFC CUSHION for S-52 1 *
81 432 510 0020 01D PWB CUSHION 4 *
82 nsp SP BOX CUSHION 1 *
83 nsp PEF SHEET (L) 1 *
84 nsp PEF SHEET (R) 1 *
85 nsp SP BOX SPACER 2 *
86 nsp SP CABLE CUSHION 1 *
87 nsp SP CABLE CUSHION R 1 *
88 nsp NOISE INSULATE SHEET 1 *
Ref. No. Part No. Part Name Remarks Q'ty New
