173
Barcode Handy Terminal
*1 The dotted line ( ndicates that the width o
the barcode label (* the readable width
the BHT-904B/BHT
bar: Wide bar = 1 : 2.5
*3
Under the following conditions:
- Ambient illuminance: 500 Lx. (Xenon arc lamp)
- EAN-13
- Reflection intensity of white bars: 85% min.
Reflection intensity of black bars: 5% max.
- 1.0 magnification, PCS value: 0.9 min.
*4 Under the following conditions:
- Ambient illuminance: 500 Lx. (Xenon arc lamp)
- ITF conforming to the UPC Shipping Container Code
- Reflection intensity of white bars: 85% min.
Reflection intensity of black bars: 5% max.
- 1.0 magnifications, PCS value: 0.9 min.
*5
Under the following conditions:
- Ambient illuminance: 500 Lx. (Xenon arc lamp)
- ITF conforming to the UPC Shipping Container Code
- Reflection intensity of white bars: 85% min.
Reflection intensity of black bars: 5% max.
- 1.0 magnifications, PCS value: 0.9 min.
*6 Under the following conditions:
- Ambient illuminance: 500 Lx. (fluorescent lamp)
- ITF conforming to the UPC Shipping Container Code
- Reflection intensity of white bars: 85% min.
Reflection intensity of black bars: 5% max.
- 1.2 magnifications.
) i
5, *6) exceeds
-914B.
f
of
*2 Under the following conditions:
- Ambient illuminance: 500 Lx. (Xenon arc lamp)
- Code 39, 4 digits
Narrow
- Reflection intensity of white bars: 85% min.
Reflection intensity of black bars: 5% max.
PCS value: 0.9 min.
