176
BHT-904B/BHT-914B
9.1 CU-900, CH-900 Specifications
9.1.1 Hardware Specifications
CU-901 CU-911 CU-921
Power supply: 100/230 V AC
(Using dedicated AC
adapter)
100/230 V AC
(Using dedicated AC
adapter)
Powered from the USB
interface*
Max. power consumption: 7 VA 8 VA 5V 500mA
Dimensions (W) x (L) x (H): 75×96.5×49 mm 75×93.5×49 mm 75×93.5×49 mm
Weight: 72 g 75 g 65 g
Ambient operating temperature: 0 to 40 C
Ambient operating humidity: 20 to 80% (with no dew condensation)
* The CU-921 can be powered also from the AC adapter.
CH-951 CH-954
Power supply: 100/230 V AC
(Using dedicated AC adapter)
100/230 V AC
(Using dedicated AC adapter)
Max. power consumption: 7 VA 18 VA
Dimensions (W) x (L) x (H): 75×93.5×49 mm 300.9×96×49 mm
Weight: 65 g 230 g
Ambient operating temperature: 0 to 40 C
Ambient operating humidity: 20 to 80% (with no dew condensation)
9.1.2 Charging Requirements
Charge current: Approx. 180 mA
Charging time: Approx. 11 hours
