 Removing the USB cable lock
[NOTE]
USB cable lock must be removed before removing the USB cable.
Press the lock release on both sides and remove it from the main unit.
USB cable lock
Lock
release
Lock
release
USB cable
T03034J
1
7-2. Connecting to the PC
[NOTE]
-
Do not apply excessive force on the lock release.
-
Pull the USB cable lock straight back to move it.
