1.2 Technical data
Note:
The units Multimat2 Touch und Multimat2 Touch+Press are delivered in 2 different voltage systems,
including a power lead (as required for the country in which it is operated):
• 100 – 125 Volt ~ / 50/60 Hz
• 230 – 240 Volt ~ / 50/60 Hz
Check the voltage rating of your unit on the type plate, which is located on the rear of the unit. Make sure that the
voltage rating and the supplied power cord are appropriate for your local power network.
Multimat2 Touch Multimat2 Touch+Press
Power consumption 1,350 W (without vacuum pump) 1,350 W (without vacuum pump)
Pump connection As mains voltage, max. 2.5 A As mains voltage, max. 2.5 A
Overvoltage category II II
Protection class I I
Instrument fuses 100 — 125 V : 2 x 10 AT 100 — 125 V : 2 x 10 AT
230 — 250 V : 2 x 6.3 AT 230 — 250 V : 2 x 6.3 AT
Degree of contamination 2 2
Weight 22 kg 25 kg
Dimensions H/W/D 441/320/425 mm closed 593/320/425 mm closed
Dimensions H/W/D 585/320/425 mm opened 748/320/425 mm opened
Input compressed air pressure – 2,7 bar
1.3 Environment conditions
Environment temperature: 2 °C to 40 °C (35,6 °F to 104 °F)
Relative humidity: max. 80 % at 31 °C (87,8 °F)
Altitude: max. 3500 m above sea level
