HD2000 IP User Manual
Copyright © 2015 SAS HENRI DEPAEPE Page 30 of 52
a. xx+ - at least 2 digit number;
b. ^ - exclude;
c. [3-5] - any digit of 3, 4, or 5;
d. [147] - any digit 1, 4, or 7;
e. <2=011> - replace digit 2 with 011 when dialing
• Example 1: {[369]11 | 1617xxxxxxx} –
Allow 311, 611, 911, and any 10 digit numbers of leading digits 1617
• Example 2: {^1900x+ | <=1617>xxxxxxx} –
Block any number of leading digits 1900 and add prefix 1617 for any
dialed 7 digit numbers
• Example 3: {1xxx[2-9]xxxxxx | <2=011>x+} –
Allow any length of number with leading digit 2 and 10 digit-numbers
of
leading digit 1 and leading exchange number between 2 and 9; If
leading
digit is 2, replace leading digit 2 with 011 before dialing
3. Default: Outgoing - {x+}
Default is No. When set to “Yes” a SUBSCRIBE for Message Waiting
Indication will be sent periodically.
If this parameter is set to “Yes”, the “From” header in outgoing INVITE
message will be set to anonymous, essentially blocking the Caller ID
from displaying.
Default is No. If set to Yes, incoming calls with anonymous Caller ID
will be rejected with 486 Busy message.
When the phone receive INVITE, at first it will check if it is right the
‘To’ in the message.
Enable or disable the ‘auto answer’ feature
Allow Auto Answer By
Call-Info
Enable or disable ‘auto answer’ when some call use Call-info to activate
this feature.
Turn off Speaker on
remote disconnect
When the remote user hang up, the phone will disable the speaker.
The SIP Session Timer extension enables SIP sessions to be
periodically “refreshed” via a SIP request (UPDATE, or re-INVITE.
Once the session intervaexpires, if there is no refresh via a UPDATE or
re-INVITE message, the session is terminated.
Session Expiration is the time (in seconds) at which the session is
considered timed out, provided no successful session refresh transaction
occurs beforehand.
The default value is 180 seconds.
